Sharp MX-2314N Service Manual

MX-3114N OPERATIONAL DESCRIPTIONS 13 – 44
I. Waste toner collection section
(1) Electrical and mechanism relation diagram
#0&-
4.&$
0&#?(0&#








0#507"
#:(
"504:3
#.
""0($33
$'.$
$'.$
4.&$ 4.&$
-&

  

 

 
#.
""0($33
""0!3+
#0&-?$ #0&-?#.4 #0&-?#,+ #0&-?,$
6.
#0&-?$
#0&-?#,+ #0&-?#.4 #0&-?,$ 6
#.
""0($33
3-06.# 3-26.
 
 
 
6 0&#?(0&#
(0&# 6


137"13::
82(0
$'.$
4.&$
Signal name Name Function/Operation
CPFM Paper feed motor Drives the paper feed section.
PFC_HPFC Transport roller clutch Controls the transport roller 4. /Drives the waste toner transport section.
TNFD Waste toner full detector Detects full of waste toner.
No. Name Function/Operation
1 Waste toner transport screw Transports waste toner to the waste toner box.
2 Waste toner box Collects waste toner.

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
