Sharp MX-M264N Service Manual

MX-M264U SIMULATION 6 – 43
44
44-1
Purpose
Setting
Function (Purpose)
Used to set each correction operation func-
tion in the image forming (process) section.
Section
Image process (Photoconductor/Develop-
ing/Transfer/Cleaning)
Operation/Procedure
1) Select an item to be set with the touch panel.
(The selected item is highlighted.)
2) Press [EXECUTE] key. (The set value is saved.)
CAUTION: Set the items to the default values unless a change is
specially required.
44-9
Purpose
Operation data display
Function (Purpose)
Used to display the result data of the high
density process control operation.
Section
Image process (Photoconductor/Develop-
ing/Transfer/Cleaning)
Operation/Procedure
Select a target display mode with [CPY/PRN], [OTHER] keys.
Item/Display Content Setting range Default value NOTE
MD_VG Membrane decrease (GB) Enable/Disable setting Black text on
white
background
(Inhibit: 0=NO)
White text on
black
background
(Allow: 1=YES)
Enable
MD_DV_LIFE DV life correction (GB, DVD) Enable/Disable setting Enable
MD_ENV Environment correction (GB, DVD) Enable/Disable setting Enable
MD_DUPLEX Duplex print correction (GB, DVD) Enable/Disable setting Enable
MD_LD Membrane decrease life correction (laser power) Enable/Disable setting Enable
MD_LD_ENV Environment correction (laser power) Enable/Disable setting Enable
TN_LIFE Enable/Disable setting of the toner density life correction Enable
TN_ENV Enable/Disable setting of the toner density environment correction Enable
TN_DUPLEX Toner density duplex print correction Enable/Disable setting Enable
TN_COV Enable/Disable setting of the toner density print ratio correction Enable
TN_AREA Enable/Disable setting of the toner density area correction Enable
TN_DRIP Enable/Disable setting of the toner density correction unconditional supply Enable
TC Enable/Disable setting of the transfer output correction Enable
Mode Page number
Item/Display
(*: Correction
value)
Content Display range
Default
value
CPY/
PRN*
1
1/2 (PROCESS) REF (TS_OFF) Left GB *** GB/DVB default value when TS is OFF 0 - 750 590
Right DVB *** 0 - 650 450
ALL (TS_OFF) Left GB *** GB/DVB value after addition or
subtraction of the correction amount
when TS is OFF
0 - 750 590
Right DVB *** 0 - 650 450
REF (TS_ON_C) Left GB *** Copy GB/DVB default value when TS is
ON
0 - 750 460
Right DVB *** 0 - 650 320
ALL(TS_ON_C) Left GB *** GB/DVB value after addition or
subtraction of the correction amount
when Copy TS is ON.
0 - 750 460
Right DVB *** 0 - 650 320
REF (TS_ON_P) Left GB *** Printer GB/DVB default value when TS is
ON
0 - 750 390
Right DVB *** 0 - 650 250
ALL (TS_ON_P) Left GB *** GB/DVB value after addition or
subtraction of the correction amount
when Printer TS is ON
0 - 750 390
Right DVB *** 0 - 650 250
MD_VG Left GB *** Drum membrane decrease correction
amount GB value
0 - 255 0
MD_DV_LIFE Left GB *** Process developer life correction amount
GB/DVB value
–127 - +127 0
Right DVB *** –127 - +127 0
MD_ENV Left GB *** Environment correction amount GB/DVB
value
–127 - +127 0
Right DVB *** –127 - +127 0
MD_DUPLEX Left GB *** Duplex print correction amount GB/DVB
value
0 - 255 0
Right DVB *** 0 - 255 0
