Sharp MX-M264N Service Manual

MX-M264U SIMULATION 6 – 44
*1: The left of the correction amount indicates the execution result, and the right indicates the reference value.
Default values for each item
CPY/
PRN*
1
2/2 (LD) REF (TS_OFF) Left LD (CP) Laser power default value when TS is
OFF (CP/PRT)
0 - 255 For default
values refer
to "Default
values for
each item".
Right LD (PRT) 0 - 255
ALL (TS_OFF) Left LD (CP) Laser power value after addition or
subtraction of the correction amount
when TS is OFF (CP/PRT)
0 - 255
Right LD (PRT) 0 - 255
REF (TS_ON_C) Left LD (CP) Laser power default value when TS is ON
(CP/PRT)
0 - 255
Right LD (PRT) 0 - 255
ALL (TS_ON_C) Left LD (CP) Laser power value after addition or
subtraction of the correction amount
when Copy TS is ON (CP/PRT)
0 - 255
Right LD (PRT) 0 - 255
MD_LD Left LD (CP) Drum membrane decrease laser power
correction amount (CP/PRT)
–127 - +127 0
Right LD (PRT) –127 - +127 0
MD_LD_ENV Left LD (CP) Environment laser power correction
amount (CP/PRT)
–127 - +127 0
Right LD (PRT) –127 - +127 0
OTHER 1/2
(TN/TC/MD)
TN_TMP_AREA *** Toner control display temperature/
humidity area
1 - 8 4
TN_TMP_DATA *** Toner control display temperature AD
value
0 - 1023 0
TN_HUD_DATA *** Toner control display humidity AD value 0 - 1023 0
TC_TMP_AREA *** Transfer display temperature/humidity
area
1 - 8 4
TC_TMP_DATA *** Transfer display temperature AD value 0 - 1023 0
TC_HUD_DATA *** Transfer display humidity AD value 0 - 1023 0
MD_VG_AREA *** Membrane decrease drum traveling
distance area
1 - 15 1
MD_DV_LIFE_AREA *** Developer life area for process 0 - 15 1
MD_ENV_AREA *** Environment correction area 1 - 8 1
MD_DUPLEX_COUNTER *** Duplex counter 0 - 300 0
MD_LD_AREA *** Laser power area 0 - 15 1
MD_LD_ENV_AREA *** Laser power environment area 0 - 8 4
2/2
(CRUM/CNT)
DESTINATION Left xx Machine side management CRUM
destination
––
MODEL TYPE xx Model type of the machine 0 - 1 0
CRUM DEST_K Right xx Crum destination – –
Mode Page number
Item/Display
(*: Correction
value)
Content Display range
Default
value
Mode Item/Display
Default value
35cpm machine 31cpm machine 26cpm machine
CPY/
PRN
REF (TS_OFF) LD (CP) 181 163 145
LD (PRT) 181 163 145
ALL (TS_OFF) LD (CP) 181 163 145
LD (PRT) 181 163 145
REF (TS_ON_C) LD (CP) 181 163 145
LD (PRT) 181 163 145
ALL (TS_ON_C) LD (CP) 181 163 145
LD (PRT) 181 163 145
