MX-M264U SIMULATION 6 – 45
44-14
Purpose
Operation data display
Function (Purpose)
Used to display the output level of the tem-
perature and humidity sensor.
Section
Process (OPC drum, development)/Fusing/
LSU
Operation/Procedure
The output levels of the fusing temperature sensor, the machine
temperature sensor, and the humidity sensor are displayed.
44-43
Purpose
Data display
Function (Purpose)
Used to display the identification informa-
tion of the developing unit.
Section
Developing system
Operation/Procedure
The identification number and the identification signal level of the
developing unit are displayed.
46
46-2
Purpose
Adjustment (Monochrome copy mode)
Function (Purpose)
Used to adjust the copy density in the copy
mode.
Section
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
* When the key is pressed, the setting value of each
item can be changed with 1up (1down) collectively.
3) Press [OK] key. (The set value is saved.)
To adjust the copy density in the low density area, select the "LOW"
mode and change the adjustment value. To adjust the copy density
in the high density area, select the "HIGH" mode and change the
adjustment value.
When the adjustment value is increased, the copy density is
increased. When the adjustment value is decreased, the copy den-
sity is decreased.
46-4
Purpose
Adjustment (Color scanner mode)
Function (Purpose)
Used to adjust the density in the image
send mode.
Section
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
* When the key is pressed, the setting value of each
item can be changed with 1up (1down) collectively.
3) Press [OK] key. (The set value is saved.)
When the adjustment value is increased, the image density is
increased, and vice versa.
Item/
Display
Content Display range
TH_UM Fusing upper thermistor main
detection temperature
Fusing upper thermistor main
detection temperature A/D value
Temperature:
0 - 255C (1C)
AD value: 0-1023
TH_US Fusing upper thermistor sub
detection temperature
Fusing upper thermistor sub
detection temperature A/D value
Temperature:
0 - 255C (1C)
AD value: 0-1023
TH_RA Temperature thermistor
Temperature thermistor A/D value
Temperature:
–40.0-60.0C (0.1C)
AD value: 0-123
HUD_RA Humidity sensor
Humidity sensor A/D value
Humidity:
5.0-90.0% (0.1%)
AD value: 0-1023
Item/Display Content
Display
range
NOTE
A DVCH
KIND K
K developing unit
identification
number
1 - 9 The model
identification number of
the developing unit
which is backed up in
the EEPROM of the
machine.
B DV_TYP_
SEL_K
K developing unit
identification
detection
0 - 1 0 = High (Open)
1 = Low (GND)
C DVCH_
AD_K
K developing unit
identification AD
value
0 - 255 AD value of the
developing unit
identification voltage
Item/Display Content
Setting
range
Default
value
A AUTO1 Auto 1 LOW 1 - 99 50
HIGH 1 - 99 50
B AUTO2 Auto 2 LOW 1 - 99 50
HIGH 1 - 99 50
C TEXT Text LOW 1 - 99 50
HIGH 1 - 99 50
D TEXT/PRINTED
Text/Printed
LOW 1 - 99 50
HIGH 1 - 99 50
E TEXT/PHOTO Text/
Photograph
LOW 1 - 99 50
HIGH 1 - 99 50
F PRINTED PHOTO Printed Photo LOW 1 - 99 50
HIGH 1 - 99 50
G PHOTOGRAPH Photograph LOW 1 - 99 50
HIGH 1 - 99 50
H MAP Map LOW 1 - 99 50
HIGH 1 - 99 50
Mode Item/Display Content
Setting
range
Default
value
LOW A AUTO Auto 1 - 99 50
B TEXT Text 1 - 99 50
C TEXT/PRINTED
Text/Printed Photo 1 - 99 50
D TEXT/PHOTO Text/Photograph 1 - 99 50
E PRINTED PHOTO Printed Photo 1 - 99 50
F PHOTOGRAPH Photograph 1 - 99 50
GMAP Map 1 - 99 50
HIGH A AUTO Auto 1 - 99 50
B TEXT Text 1 - 99 50
C TEXT/PRINTED
Text/Printed Photo 1 - 99 50
D TEXT/PHOTO Text/Photograph 1 - 99 50
E PRINTED PHOTO Printed Photo 1 - 99 50
F PHOTOGRAPH Photograph 1 - 99 50
GMAP Map 1 - 99 50
