MX-M264U SIMULATION 6 – 46
46-5
Purpose
Adjustment (Monochrome scanner mode)
Function (Purpose)
Used to adjust the density in the image
send mode.
Section
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
* When the key is pressed, the setting value of each
item can be changed with 1up (1down) collectively.
3) Press [OK] key. (The set value is saved.)
When the adjustment value is increased, the image density is
increased, and vice versa.
46-8
Purpose
Adjustment (Color scanner mode)
Function (Purpose)
Used to adjust the image send mode color
balance RGB.
Section
Operation/Procedure
1) Select an adjustment target with [R] [G] [B] keys on the touch
panel.
2) Select an adjustment target item with scroll key on the touch
panel.
3) Enter the set value with 10-key.
4) Press [OK] key. (The set value is saved.)
The color balance can be adjusted separately for the low density
area and the high density area.
When the adjustment value is increased, the image density of the
target color is increased, and vice versa.
46-9
Purpose
Adjustment (RSPF mode)
Function (Purpose)
Used to adjust the scan image density.
Section
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
* When the key is pressed, the setting value of each
item can be changed with 1up (1down) collectively.
3) Press [OK] key. (The set value is saved.)
This adjustment result affects the image send mode, the copy
mode, and the fax mode.
When the adjustment value is increased, the image density is
increased, and vice versa.
46-19
Purpose
Setting
Function (Purpose)
Used to set the operating conditions for the
density scanning (exposure) of mono-
chrome auto copy mode documents.
Section
Operation/Procedure
Select an item to be set with touch panel.
When an item is selected, it is highlighted and the setting change is
saved.
NOTE:
Mode Item/Display Content
Setting
range
Default
value
LOW A AUTO TEXT Auto/Text 1 - 99 50
B TEXT Text 1 - 99 50
CTEXT/PRINTED
Text/Printed Photo 1 - 99 50
D TEXT/PHOTO Text/Photograph 1 - 99 50
E PRINTED PHOTO Printed Photo 1 - 99 50
F PHOTOGRAPH Photograph 1 - 99 50
G MAP Map 1 - 99 50
HIGH A AUTO TEXT Auto/Text 1 - 99 50
B TEXT Text 1 - 99 50
CTEXT/PRINTED
Text/Printed Photo 1 - 99 50
D TEXT/PHOTO Text/Photograph 1 - 99 50
E PRINTED PHOTO Printed Photo 1 - 99 50
F PHOTOGRAPH Photograph 1 - 99 50
G MAP Map 1 - 99 50
Item/Display Content
Default
value
A LOW DENSITY POINT Low density correction amount 50
B HIGH DENSITY POINT High density correction amount 50
Item/Display Content
Setting
range
Default
value
A COPY : LOW RSPF copy mode exposure
adjustment (Low density side)
1 - 99 48
B SCAN : LOW RSPF scanner mode exposure
adjustment (Low density side)
1 - 99 48
C FAX : LOW RSPF FAX mode exposure
adjustment (Low density side)
1 - 99 48
D COPY : HIGH RSPF copy mode exposure
adjustment (High density side)
1 - 99 53
E SCAN : HIGH RSPF scanner mode exposure
adjustment (Low density side)
1 - 99 53
F FAX : HIGH RSPF FAX mode exposure
adjustment (high density)
1 - 99 53
Item/Display Content Set value
Default
value
AE_MODE Auto exposure mode MODE1, MODE2 MODE2
AE_STOP_COPY Auto B/W exposure
Stop (for copy)
REALTIME/
STOP/
PRESCAN
STOP
AE_STOP_FAX Auto B/W exposure
Stop (for FAX)
ON/OFF ON
AE_STOP_SCAN Auto B/W exposure
Stop (for scanner)
REALTIME/
STOP/
PRESCAN
STOP
AE_FILTER Auto exposure filter
setting
SOFT NORMAL
NORMAL
SHARP
AE_WIDTH AE exposure width FULL/PART PART
MODE 1 High gamma (high contrast images)
MODE 2 Normal gamma
STOP The image density in 3 - 7mm area at the lead edge is
scanned, and the output image density is determined
according to the scanned density. (The output image density
is even for all the surface.)
REALTIME The densities of the document width are scanned
sequentially, and the output image density is determined
according to the density in each area of document. (The
output image density may not be even for all the surface.)
PRESCAN The densities of the all surface of document are scanned
sequentially, and the output image density is determined
according to the average of the scanned densities. (The
output image density is even for all the surface.)
AE WIDTH
FULL
The document density scan area in the monochrome auto
mode is 3 - 7mm at the document lead edge x the document
width. This is not related to the PRESCAN mode.
AE WIDTH
PART
The document density scan area in the monochrome auto
mode is 3 - 7mm at the document lead edge x 100mm
width. This is not related to the PRESCAN mode.
