MX-M264U SIMULATION 6 – 49
46-43
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the FAX send image density.
(Super Fine)
Section
Operation/Procedure
1) Set the document on the document table.
2) Enter the set value with 10-key.
3) Press [EXECUTE] key, or [OK] key
When [EXECUTE] key is pressed, the adjustment value is set
and the scanned document image is outputted.
To check the adjustment density level of items A - L, set the docu-
ment and set the setting value of item M according to items A - L,
and press [EXECUTE] key.
46-44
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the FAX send image density.
(Ultra fine)
Section
Operation/Procedure
1) Set the document on the document table.
2) Enter the set value with 10-key.
3) Press [EXECUTE] key, or [OK] key
When [EXECUTE] key is pressed, the adjustment value is set
and the scanned document image is outputted.
To check the adjustment density level of items A - L, set the docu-
ment and set the setting value of item M according to items A - L,
and press [EXECUTE] key.
Item/Display Content
Setting
range
Default
value
A AUTO Super Fine/Auto 1 - 99 50
B EXPOSURE1 Super Fine/
Exposure 1
1 - 99 50
C EXPOSURE2 Super Fine/
Exposure 2
1 - 99 50
D EXPOSURE3 Super Fine/
Exposure 3
1 - 99 50
E EXPOSURE4 Super Fine/
Exposure 4
1 - 99 50
F EXPOSURE5 Super Fine/
Exposure 5
1 - 99 50
G AUTO H_TONE Super Fine/
Auto/Halftone
1 - 99 50
H EXPOSURE1 H_TONE Super Fine/
Exposure 1/Halftone
1 - 99 50
I EXPOSURE2 H_TONE Super Fine/
Exposure 2/Halftone
1 - 99 50
J EXPOSURE3 H_TONE Super Fine/
Exposure 3/Halftone
1 - 99 50
K EXPOSURE4 H_TONE Super Fine/
Exposure 4/Halftone
1 - 99 50
L EXPOSURE5 H_TONE Super Fine/
Exposure 5/Halftone
1 - 99 50
M EXECUTE
MODE
AUTO Print
mode
Super Fine/
Auto
1 -
12
11
(AUTO)
EXP1 Super Fine/
Exposure 1
2
EXP2 Super Fine/
Exposure 2
3
EXP3 Super Fine/
Exposure 3
4
EXP4 Super Fine/
Exposure 4
5
EXP5 Super Fine/
Exposure 5
6
AUTO
H_TONE
Super Fine/
Auto/
Halftone
7
EXP1
H_TONE
Super Fine/
Exposure 1/
Halftone
8
EXP2
H_TONE
Super Fine/
Exposure 2/
Halftone
9
EXP3
H_TONE
Super Fine/
Exposure 3/
Halftone
10
EXP4
H_TONE
Super Fine/
Exposure 4/
Halftone
11
EXP5
H_TONE
Super Fine/
Exposure 5/
Halftone
12
Item/Display Content
Setting
range
Default
value
A AUTO Ultra Fine/Auto 1 - 99 50
B EXPOSURE1 Ultra Fine/Exposure 1 1 - 99 50
C EXPOSURE2 Ultra Fine/Exposure 2 1 - 99 50
D EXPOSURE3 Ultra Fine/Exposure 3 1 - 99 50
E EXPOSURE4 Ultra Fine/Exposure 4 1 - 99 50
F EXPOSURE5 Ultra Fine/Exposure 5 1 - 99 50
G AUTO H_TONE Ultra Fine/Auto/
Halftone
1 - 99 50
H EXPOSURE1
H_TONE
Ultra Fine/
Exposure 1/Halftone
1 - 99 50
I EXPOSURE2
H_TONE
Ultra Fine/
Exposure 2/Halftone
1 - 99 50
J EXPOSURE3
H_TONE
Ultra Fine/
Exposure 3/Halftone
1 - 99 50
K EXPOSURE4
H_TONE
Ultra Fine/
Exposure 4/Halftone
1 - 99 50
L EXPOSURE5
H_TONE
Ultra Fine/
Exposure 5/Halftone
1 - 99 50
M EXECUTE
MODE
AUTO Print
mode
Ultra Fine/
Auto
1 -
12
11
(AUTO)
EXP1 Ultra Fine/
Exposure 1
2
EXP2 Ultra Fine/
Exposure 2
3
EXP3 Ultra Fine/
Exposure 3
4
EXP4 Ultra Fine/
Exposure 4
5
EXP5 Ultra Fine/
Exposure 5
6
AUTO
H_TONE
Ultra Fine/
Auto/
Halftone
7
EXP1
H_TONE
Ultra Fine/
Exposure 1/
Halftone
8
EXP2
H_TONE
Ultra Fine/
Exposure 2/
Halftone
9
EXP3
H_TONE
Ultra Fine/
Exposure 3/
Halftone
10
EXP4
H_TONE
Ultra Fine/
Exposure 4/
Halftone
11
EXP5
H_TONE
Ultra Fine/
Exposure 5/
Halftone
12
