MX-M264U SIMULATION 6 – 51
46-60
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the sharpness in the color
auto copy mode.
Section
Operation/Procedure
1) Select a target item with scroll keys on the touch panel.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value is saved.
46-61
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the area separation recogni-
tion level.
Section
Operation/Procedure
1) Select an adjustment mode.
2) Select a target adjustment item with scroll key on the touch
panel.
3) Enter the adjustment value using the 10-key.
4) Press [OK] key.
The set value is saved.
CAUTION: This must be set to the default unless any change is
specially required.
When the adjustment value is set to a value greatly dif-
ferent from the default value, image quality trouble may
occur for some documents.
Item/Display Content
Setting
range
Default
value
A SCREEN
FILTER
LEVEL
H Sharpness
(filter)
adjustment
of dot
pattern
image in
auto copy
mode
Strong
emphasis
13 (Auto)
L Soft
emphasis
2
AUTO Auto 3
BCPY
PUSH
AUTO
FILTER
LEVEL
SOFT Sharpness
(filter)
adjustment
for the
automatic
push scan
mode
(Text,
Printed
Photo /
Printed
images)
SOFT 1 2
(CENTER)
CENTER CENTER 2
HIGH HIGH 3
CB/W
COPY
OFF Soft filter
applying
setting in
monochro
me copy
mode
OFF 0 1 (ON)
ON ON 1
DCOLOR
PUSH :
RGB
OFF Soft filter
applying
setting to
image in
push scan
color mode
OFF 0 1 (ON)
ON ON 1
EB/W
PUSH
OFF Soft filter
applying
setting to
image in
push scan
monochro
me mode
OFF 0 1 (ON)
ON ON 1
FB/W
PRINT
OFF Setting of
ON/OFF of
soft filter
application
to
monochro
me print
images
OFF 0 0 (OFF)
ON ON 1
Item/Display Content
COLOR AUTO [Color/Gray] Auto
TPP [Color/Gray] Manual (Text print)
MONO AUTO [Monochrome] Auto
TPP [Monochrome] Manual (Text print)
Item/Display Content
Setting
range
Default
value
A SEGMENT: SWITCH
[TXT ON SCR]
Detection ON/OFF:
Text on dot
0 - 1 0
B SEGMENT: SWITCH
[LINE SCR]
Detection ON/OFF:
line screen
0 - 1 0
C SEGMENT: SWITCH
[SMALL SCR]
Detection ON/OFF:
Dot in a small area
0 - 1 0
D SEGMENT: SWITCH
[HIGH LPI]
Detection ON/OFF:
High line number
judgment select
0 - 1 0
E SEGMENT: SWITCH
[TXT ON SCR IMAGE
SEND]
Detection ON/OFF:
Text on image send
dots
0 - 1 0
F SEGMENT: ADJUST
[BK TXT 1]
Detection level
adjustment: Black text
1
1 - 99 50
G SEGMENT: ADJUST
[CL TXT 1]
Detection level
adjustment: Color text
1
1 - 99 50
H SEGMENT: ADJUST
[BK TXT 2, CL TXT 2]
Detection level
adjustment: Black text
2, Color text 2
1 - 49 25
I SEGMENT: ADJUST
[TXT ON SCR 1]
Detection level
adjustment: Text 1 on
dots
1 - 99 50
J SEGMENT: ADJUST
[TXT ON SCR 2]
Detection level
adjustment: Text 2 on
dots
1 - 99 50
K SEGMENT: ADJUST
[TXT ON SCR AREA]
Detection level
adjustment: Detection
area of text on dots
1 - 15 8
L SEGMENT: ADJUST
[HIGH LPI]
Detection level
adjustment: High line
number judgment
1 - 49 25
M SEGMENT: ADJUST
[BK]
Detection level
adjustment: No
chrome judgment
1 - 99 50
N SEGMENT: ADJUST
[CL]
Detection level
adjustment: Chrome
judgment
1 - 99 50
O SEGMENT: ADJUST
[TXT ON BG]
Detection level
adjustment: Text on
background
1 - 99 50
P SEGMENT: ADJUST
[SCR 1 HIGH]
Detection level
adjustment: High
density dots
1 - 49 25
