MX-M264U SIMULATION 6 – 52
46-62
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the operating conditions of the
ACS, the area separation, the background
image process, and the auto exposure
mode.
Section
Operation/Procedure
1) Select a target adjustment item with scroll key on the touch
panel.
2) Enter the adjustment value using the 10-key.
3) Press [OK] key.
The set value is saved.
CAUTION: This must be set to the default unless any change is
specially required.
When the adjustment value is set to a value greatly dif-
ferent from the default value, image quality trouble may
occur for some documents.
46-63
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the density in the copy low
density section.
Section
Operation/Procedure
1) Select a target adjustment item with scroll key on the touch
panel.
2) Enter the adjustment value using the 10-key.
3) Press [OK] key.
The set value is saved.
When the adjustment value is increased, reproducibility of the
background and the low density image is increased. When the
adjustment value is decreased, reproducibility of the background
and the low density image is decreased.
Q SEGMENT: ADJUST
[SCR 1 MIDDLE]
Detection level
adjustment: Medium
density dots
1 - 49 25
R SEGMENT: ADJUST
[SCR 1 LOW]
Detection level
adjustment: Low
density dots
1 - 49 25
S SEGMENT: ADJUST
[SCR 2]
Detection level
adjustment: Dot 2
1 - 15 8
T SEGMENT: ADJUST
[SCR 3]
Detection level
adjustment: Dot 3
1 - 15 8
U SEGMENT: ADJUST
[LINE HALFTONE]
Detection level
adjustment: line
screen
1 - 49 25
Item/Display Content
Setting
range
Default
value
A SW_ACS ACS judgment reference
area select
0 - 1 1
B TEXT_IMAGE Text/Image judgment
priority level adjustment
0 - 6 3
C TEXT_BLANK Text/Blank judgment
priority level adjustment
0 - 6 4
D HT_LV Dot area judgment
threshold value
adjustment
0 - 6 1
E AE_AREA_LV Color AE judgment target
area adjustment
0 - 6 3
F AE_LV_CC AE background detection
division result
adjustment:
For color copy
0 - 8 4
G AE_LV_MC AE background detection
division result
adjustment:
For monochrome copy
0 - 8 4
H AE_LV_CS AE background detection
division result
adjustment:
For color scan
0 - 8 4
I AE_LV_MS AE background detection
division result
adjustment:
For monochrome scan
0 - 8 4
J AE_JUDGE_
LV_L_U
Color AE background
density threshold value
adjustment (lower limit)
0 - 4 0
K AE_JUDGE_
LV_L_O
Color AE background
density threshold value
adjustment (upper limit)
0 - 10 0
Item/Display Content
Setting
range
Default
value
L AE_JUDGE_
LV_C
Color AE background
detection level
adjustment (chroma)
0 - 10 5
MAE_
ONOFF_
CC
ON AE mode ON/
OFF switch:
For color copy
ON 0 - 1 0 0 (ON)
OFF OFF 1
NAE_
ONOFF_
MC
ON AE mode ON/
OFF switch:
For mono-
chrome copy
ON 0 - 1 0 0 (ON)
OFF OFF 1
OAE_
ONOFF_
CS
ON AE mode ON/
OFF switch :
For color scan
ON 0 - 1 0 0 (ON)
OFF OFF 1
PAE_
ONOFF_
MS
ON AE mode ON/
OFF switch :
For mono-
chrome copy
ON 0 - 1 0 0 (ON)
OFF OFF 1
Q BLANK_JUDGE_
LV_L
Blank judgment level
adjustment (value)
0 - 10 0
R BLANK_JUDGE_
LV_C
Blank judgment level
adjustment (chroma)
0 - 10 0
S MODE0_UNDER Mode 0 developing
paper mode select
0 - 6 0
T MODE1_UNDER Mode 1 developing
paper mode select
0 - 6 0
U MODE5_UNDER Mode 5 developing
paper mode select
0 - 6 0
V MODE6_UNDER Mode 6 developing
paper mode select
0 - 6 0
Item/Display Content
Setting
range
Default
value
A COLOR COPY :
TEXT/PRINTED PHOTO
Text prin t
(color copy)
1 - 9 3
B COLOR COPY : TEXT Text (color copy) 1 - 9 3
C COLOR COPY :
PRINTED PHOTO
Printed photo
(color copy)
1 - 9 5
D COLOR COPY :
PHOTOGRAPH
Photograph
(color copy)
1 - 9 5
E COLOR COPY :
TEXT/PHOTO
Text/Photograph
(color copy)
1 - 9 3
F COLOR COPY : MAP Map (color copy) 1 - 9 5
G COLOR COPY : LIGHT Light document
(color density)
1 - 9 6
H COLOR COPY :
TEXT/PRINTED PHOTO
(COPY TO COPY)
Copy document,
Character print
(color copy)
1 - 9 5
I COLOR COPY : TEXT
(COPY TO COPY)
Copy document,
Character
(color copy)
1 - 9 5
J COLOR COPY :
PRINTED PHOTO (COPY
TO COPY)
Copy document,
Printed photo
(color copy)
1 - 9 5
Item/Display Content
Setting
range
Default
value
To Next Page
