MX-M264U SIMULATION 6 – 53

48-1

Purpose

Adjustment

Function (Purpose)

Used to adjust the scan image magnifica-

tion ratio (in the main scanning direction

and the sub scanning direction).

Section

Operation/Procedure

1) Select a target adjustment item with scroll key on the touch

panel.

2) Enter the set value with 10-key.

3) Press [OK] key.

The set value is saved.

When the adjustment value is increased, the image magnification

ratio is increased.

A change of "1" in the adjustment value of item A, C, or E corre-

sponds to a change of about 0.02% in the copy magnification ratio.

A change of "1" in the adjustment value of item B, D, or F corre-

sponds to a change of about 0.1% in the copy magnification ratio.

48-5

Purpose

Adjustment

Function (Purpose)

Used to correction the scan image magnifi-

cation ratio (in the sub scanning direction).

Section

Scanner section

Operation/Procedure

1) Select a target adjustment item with scroll key on the touch

panel.

2) Enter the set value with 10-key.

3) Press [OK] key.

The set value is saved.

When the image magnification ratio in the sub scanning direction is

adjusted with SIM48-1, and a different magnification ratio is speci-

fied, and the image magnification ratio is not satisfactory, perform

this adjustment.

When there is an error in the image magnification ratio in reduction,

change the adjustment value in the high speed mode. When there

is an error in the image magnification ratio in enlargement, change

the adjustment value in the low speed mode.

49-1

Purpose

Function (Purpose) Used to perform the firmware update.

Section

Operation/Procedure

1) Save the firmware to the USB memory.

2) Insert the USB memory into the main unit. (Use USB I/F of the

operation panel section.)

3) Select a target firmware file for update with the touch panel.

4) Select a target firmware.

Press [ALL] key to select all the Firmware collectively.

5) Press [EXECUTE] key.

6) Press [YES] key.

The selected firmware is updated.

When the operation is normally completed, "COMPLETE" is

displayed. When terminated abnormally, "ERROR" is dis-

played.

K COLOR PUSH :

TEXT/PRINTED PHOTO

Text prin t

(color PUSH)

1 - 9 3

L COLOR PUSH : TEXT Text (color PUSH) 1 - 9 3

M COLOR PUSH :

PRINTED PHOTO

Printed photo

(color PUSH)

1 - 9 5

N COLOR PUSH :

PHOTOGRAPH

Photograph

(color PUSH)

1 - 9 5

O COLOR PUSH :

TEXT/PHOTO

Text/Photograph

(color PUSH)

1 - 9 3

P COLOR PUSH : MAP Map (color PUSH) 1 - 9 5

Item/Display Content

Setting

range

Default

value

A CCD (MAIN) SCAN main scanning
