MX-M264U SIMULATION 6 – 54
49-3
Purpose
Function (Purpose) Used to update the operation manual in the
HDD.
Section
Operation/Procedure
1) Insert the USB memory into the main unit.
* When the USB is not inserted, "INSERT A STORANGE E-
MANUAL STORED ON" is displayed. When [OK] key is
pressed, the display is shifted to the folder select menu 1.
2) Press the folder button of the operation manual data. (The dis-
play is shifted to the operation manual update menu.)
The current version and the update version are displayed.
3) Press [EXECUTE] key.
[EXECUTE] key is highlighted, and [YES] [NO] keys becomes
active from gray out.
4) When [YES] key is pressed, the selected operation manual is
updated.
When update is completed normally, "COMPLETE" is dis-
played. When terminated abnormally, "ERROR" is displayed.
49-5
Purpose
Function (Purpose) Used to perform the watermark update.
Section
Operation/Procedure
1) Insert the USB memory into the main unit.
2) Select the button of the folder to perform the watermark
update.
3) The current version and the update version are displayed.
4) Press [EXECUTE] key.
5) Press [YES] key.
The selected watermark is updated.
50
50-1
Purpose
Adjustment
Function (Purpose)
Copy image position, image loss adjust-
ment
Section
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
Set the items other than RRCA, LEAD, and SIDE to the
default.
RRCA: Image lead edge reference position adjustment
LEAD: Lead edge image loss adjustment
SIDE: Side image loss adjustment
3) Press [OK] key. (The set value is saved.)
A. (RRC-A) Timing from starting document scanning to specifying
the image lead edge reference is adjusted. (01.mm/step)
* When the value is decreased, the timing is advanced. When
the value is increased, the timing is delayed.
B - E. (RRC-B) The timing to turning ON the registration roller after
receiving the registration signal is adjusted. (0.1mm/step)
* When the value is decreased, the timing is delayed. When the
value is increased, the timing is advanced.
F. (LEAD) The lead edge image loss amount is adjusted. (0.1mm/
step)
* When the value is increased, the image loss is increased.
G. (SIDE) The side image loss amount is adjusted.
* When the value is increased, the image loss is increased.
(0.1mm/step)
H. (DEN-A) The paper lead edge void amount is adjusted. (0.1mm/
step)
* When the value is increased, the void is increased.
I. (DEN-B) The paper rear edge void amount is adjusted. (0.1mm/
step)
* When the value is increased, the void is increased.
J. (FRONT/REAR) The void amount on the right and left edges of
paper is adjusted. (0.1mm/step)
SCU (BOOT) SCU Boot section SCUB
SCU (MAIN) SCU Main section SCUM
FAX (BOOT) FAX1 Boot section FAXB
FAX (MAIN) FAX1 Main section FAXM
ANIMATION Animation data ANIME
WEB HELP WEB help WEBHP
Item/Display Content
Error display in
case of abnormality
Item/Display Content
Setting
range
Default
value
A Lead
edge
adjust-
ment
value
RRCA Document lead
edge reference
position (OC)
0 - 99 50
B RRCB-
CS12
Regis-
tration
motor
ON
timing
adjust-
ment
Standard
Tray
1 - 99 50
C RRCB-DSK Desk 1 - 99 50
D RRCB-MFT Manual
paper
feed
1 - 99 50
E RRCB-ADU ADU 1 - 99 50
FImage
loss area
setting
value
LEAD Lead edge image
loss area setting
0 - 99 40
G SIDE Side image loss
area adjustment
0 - 99 20
H Void area
adjust-
ment
DENA Lead edge void
area adjustment
1 - 99 30
I DENB Rear edge void
area adjustment
1 - 99 30
J FRONT/
REAR
FRONT/REAR void
area adjustment
1 - 99 20
K Off-center
adjust-
ment
OFFSET_
OC
OC document off-
center adjustment
1 - 99 50
L Magnificat
ion ratio
correction
SCAN_
SPEED_
OC
SCAN sub scanning
magnification ratio
adjustment (CCD)
1 - 99 50
M Sub
scanning
direction
print area
correction
value
DENB-MFT Manual feed
correction value
1 - 99 57
N DENB-CS1 Tray 1 correction
value
1 - 99 50
O DENB-CS2 Tray 2 correction
value
1 - 99 57
P DENB-CS3 Tray 3 correction
value
1 - 99 57
Q DENB-CS4 Tray 4 correction
value
1 - 99 57
R DENB-ADU ADU correction
value
1 - 99 60
S DENB-HV Heavy paper
correction value
1 - 99 50
