MX-M264U SIMULATION 6 – 58
50-10
Purpose
Adjustment
Function (Purpose)
Used to adjust the black print image magni-
fication ratio and the off-center position.
(The adjustment is made separately for
each paper feed section.)
Section
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [EXECUTE] key. (The set value is saved.)
Item A - F: When the adjustment value is increased, it is shifted to the front frame side. When the adjustment value is decreased, it is shifted to
the rear frame side. 1 step = 0.1mm change
50-12
Purpose
Adjustment
Function (Purpose)
Used to perform the scan image off-center
position adjustment. (The adjustment is
made separately for each scan mode.)
Section
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key. (The set value is saved.)
When the adjustment value is increased, the image position is
shifted to the rear frame side. When the adjustment value is
decreased, it is shifted to the front frame side.
1step = 0.1mm
Item/Display Content Setting range Default value NOTE
A MAIN-MFT Print off center adjustment value (Manual paper feed) 1 - 99 50 Adjustment Item
List
B MAIN-CS1 Print off center adjustment value (Tray 1) 1 - 99 50
C MAIN-CS2 Print off center adjustment value (Tray 2) 1 - 99 50
D MAIN-CS3 Print off center adjustment value (Tray 3) 1 - 99 50
E MAIN-CS4 Print off center adjustment value (Tray 4) 1 - 99 50
F MAIN-ADU Print off center adjustment value (Duplex)
CAUTION: If the adjustment items A - F are not properly adjusted,
this adjustment cannot be executed properly.
1 - 99 50
G SUB-MFT Registration motor ON timing adjustment Manual paper feed 1 - 99 50
H SUB-CS12 Standard cassette 1 - 99 50
I SUB-DSK DESK 1 - 99 50
J SUB-ADU ADU 1 - 99 50
K MULTI COUNT Number of print 1 - 999 1 Adjustment pattern
print conditions
setting
L PAPER MFT Tray selection Manual paper feed 1 - 5 1 2 (CS1)
CS1 Tray 1 2
CS2 Tray 2 3
CS3 Tray 3 4
CS4 Tray 4 5
M DUPLEX YES Duplex print selection Yes 0 - 1 0 1 (NO)
NO No 1
Item/Display Content Setting range Default value
A OC Document table image off-center adjustment 1 - 99 50
B SPF (SIDE1) SPF front surface image off-center adjustment 1 - 99 50
C SPF (SIDE2) SPF back surface image off-center adjustment 1 - 99 50
