MX-M264U SIMULATION 6 – 60
51
51-2
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the contact pressure (deflec-
tion amount) on paper by the main unit and
the RSPF registration roller. (This adjust-
ment is performed when there is a consid-
erable variation in the print image position
on the paper or when paper jams frequently
occur.)
Section
Operation/Procedure
1) (When RSPF model)
Select a target adjustment mode with [SIDE1] or [SIDE2] or
[ENGINE] keys.
2) Select a target item to be adjusted with scroll keys.
3) Enter the set value with 10-key.
4) Press [OK] key. (The set value is saved.)
Item/Display Content Section
SETUP/
PRINT
ADJ
ALL LEAD MFT Print off
center
Print lead
edge
Print lead
edge
adjustment,
image off-
center
(each paper
feed tray,
duplex
mode)
adjustment
Engine
CS1
CS2
OFFSET ADU
CS3
CS4
RESULT Adjustment result display
DATA Adjustment operation data display
Mode Display/Item Content
Setting
range
Default
value
SIDE1 A NORMAL_PLAIN_HIGH RSPF front surface document deflection amount adjustment value
(Normal/Plain paper/HIGH)
-1 - 9950
B NORMAL_PLAIN_LOW RSPF front surface document deflection amount adjustment value
(Normal/Plain paper/LOW)
-1 - 9950
C NORMAL_THIN_HIGH RSPF front surface document deflection amount adjustment value
(Normal/Thin paper/HIGH)
-1 - 9950
D NORMAL_THIN_LOW RSPF front surface document deflection amount adjustment value
(Normal/Thin paper/LOW)
-1 - 9950
E RANDOM_PLAIN_HIGH RSPF front surface document deflection amount adjustment value
(Random/Plain paper/HIGH)
-1 - 9950
F RANDOM_PLAIN_LOW RSPF front surface document deflection amount adjustment value
(Random/Plain paper/LOW)
-1 - 9950
G RANDOM_THIN_HIGH RSPF front surface document deflection amount adjustment value
(Random/Thin paper/HIGH)
-1 - 9950
H RANDOM_THIN_LOW RSPF front surface document deflection amount adjustment value
(Random/Thin paper/LOW)
-1 - 9950
SIDE2 A NORMAL_PLAIN_HIGH_1 RSPF back surface document deflection amount adjustment value 1
(Normal/Plain paper/HIGH)
-1 - 9950
B NORMAL_PLAIN_LOW_1 RSPF back surface document deflection amount adjustment value 1
(Normal/Plain paper/LOW)
-1 - 9950
ENGINE A TRAY1(S) Main unit cassette 1 (Upper stage)/deflection adjustment value
(Plain paper/Small size)
LT size (216mm)
or less
1 - 99 25
B TRAY1(L) Main unit cassette 1 (Upper stage)/deflection adjustment value
(Plain paper/Large size)
LT size (216mm)
or above
1 - 99 25
C TRAY2(S) Main unit cassette 2 (Lower stage)/deflection adjustment value
(Plain paper/Small size)
LT size (216mm)
or less
1 - 99 50
D TRAY2(L) Main unit cassette 2 (Lower stage)/deflection adjustment value
(Plain paper/Large size)
LT size (216mm)
or above
1 - 99 50
E MANUAL PLAIN PAPER (S) Manual feed tray/deflection adjustment value (Plain paper/Small size) LT size (216mm)
or less
1 - 99 40
