MX-M264U SIMULATION 6 – 61
Note on “Large size” and “Small size”
Small size: The paper length in the transport direction is shorter than the LT size (216mm).
Large size: The paper length in the transport direction is longer than the LT size (216mm).
Adjustment value
When the adjustment value is increased, the warp amount is increased. When the adjustment value is decreased, the warp amount is
decreased.
(When the adjustment value is changed by 1, the stop timing is changed by 0.1mm.)
51-9
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the ON/OFF timing of the
separation voltage.
Section
Operation/Procedure
1) Select an adjustment target item with scroll key.
2) Enter the set value with 10-key.
3) Press [OK] key. (The set value is saved.)
*1: Transfer V2ON reference
(Synchronized with the adjustment value of 50)
*2: Transfer V2OFF reference
(Synchronized with the adjustment value of 50)
53
53-6
Purpose
Adjustment
Function (Purpose)
Used to adjust the detection level of the
RSPF document width.
Section
Operation/Procedure
1) Open the RSPF paper feed guide to the maximum width.
2) Press [EXECUTE] key.
The maximum width detection level is recognized.
3) Open the RSPF paper feed guide to the A4R width.
4) Press [EXECUTE] key.
The A4R width detection level is recognized.
5) Open the RSPF paper feed guide to the A5R width.
6) Press [EXECUTE] key.
The A5R width detection level is recognized.
7) Open the RSPF paper feed guide to the minimum width.
8) Press [EXECUTE] key.
The minimum width detection level is recognized.
When the above operation is nor performed normally, "ERROR" is
displayed and. When the above operation is completed normally,
"COMPLETE" is displayed.
53-7
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the RSPF document size
width sensor.
Section
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key. (The set value is saved.)
ENGINE F MANUAL PLAIN PAPER (L) Manual feed tray/deflection adjustment value (Plain paper/Large size) LT size (216mm)
or above
1 - 99 40
G MANUAL HEAVY PAPER (S) Manual feed tray/deflection adjustment value
(Heavy paper/Small size)
LT size (216mm)
or less
1 - 99 70
H MANUAL HEAVY PAPER (L) Manual feed tray/deflection adjustment value
(Heavy paper/Large size)
LT size (216mm)
or above
1 - 99 70
I MANUAL OHP Manual feed tray/deflection adjustment value (OHP) - 1 - 99 30
J MANUAL ENV Manual feed tray/deflection adjustment value (Envelope) - 1 - 99 40
K ADU PLAIN PAPER (S) ADU/deflection adjustment value
(Plain paper/Small size)
LT size (216mm)
or less
1 - 99 50
L ADU PLAIN PAPER (L) ADU/deflection adjustment value
(Plain paper/Large size)
LT size (216mm)
or above
1 - 99 50
M DESK (S) DESK/deflection adjustment value
(Plain paper/Small size)
LT size (216mm)
or less
1 - 99 20
N DESK (L) DESK/deflection adjustment value
(Plain paper/Large size)
LT size (216mm)
or above
1 - 99 25
Mode Display/Item Content
Setting
range
Default
value
Item Display Content
Setting
range
Default
value
A SHV ON Separation voltage ON/OFF
timing adjustment *
1
25 - 90 50
B SHV OFF Separation voltage OFF timing
adjustment *
2
50 - 90 75
1 TRAYVOLMAX Tray size volume maximum value
2 TRAYVOLA4R Tray volume A4R size adjustment value
3 TRAYVOLA5R Tray volume A5R size adjustment value
4 TRAYVOLMIN Tray size volume minimum value
Item/Display
Setting
range
Default
value
A AD_MAX Max. width position 0 - 1023 84
B AD_P1 A4R width position 0 - 1023 509
C AD_P2 A5R width position 0 - 1023 808
D AD_MIN Min. width position 0 - 1023 961
To Next Page
