MX-M264U SIMULATION 6 – 63
56
56-1
Purpose
Backup
Function (Purpose)
Used to transport data between HDD - MFP
PWB SRAM/EEPROM. (Used to repair the
PWB.)
Section
Operation/Procedure
1) Select a target content of data transfer.
2) Press [EXECUTE] key and press [YES] key.
Data transfer of the item selected in procedure 1) is executed.
When the operation is completed normally, "COMPLETE" is
displayed. In case of an abnormal end, "ERROR" is displayed.
56-2
Purpose
Data backup
Function (Purpose)
Used to backup the data in the EEPROM.
SD Card, and HDD (including user authen-
tication data and address data) to the USB
memory. (Corresponding to the device
cloning and the storage backup.)
Section
Operation/Procedure
1) Insert the USB memory into the main unit.
2) Select a target transfer item with the touch panel.
<IMPORT>
From USB MEMORY DEVICE To EEPROM, SD Card HDD
<EXPORT>
From EEPROM, SD Card, HDD To USB MEMORY
3) Press [EXECUTE] key, and press [YES] key.
Data transfer selected in the procedure 2) is performed
When the operation is completed normally, "COMPLETE" is
displayed. In case of an abnormal end, "ERROR" is displayed.
Machine with the DSK installed
1) Insert the USB memory into the main unit.
2) Select a target transfer item with the touch panel.
•IMPORT
From USB MEMORY DEVICE to EEPROM, SD Card HDD
• EXPORT
From EEPROM, SD Card, HDD to USB MEMORY DEVICE
3) Enter the password with 10-key.
4) Press [SET] key.
5) Press [EXECUTE] key, and press [YES] key.
Data transfer selected in the procedure 2) is performed.
When the operation is completed normally, "COMPLETE" is
displayed. In case of an abnormal end, "ERROR" is displayed.
Data list outside the backup targets
EEPROM/SD Card
HDD
56-3
Purpose
Data backup
Function (Purpose)
Used to backup the document filing data to
the USB memory.
Section
Operation/Procedure
1) Insert the USB memory into the main unit.
2) Select a target transfer item with the touch panel.
<IMPORT>
From USB MEMORY DEVICE to EEPROM, SD Card, HDD
<EXPORT>
From EEPROM, SD Card, HDD to USB MEMORY DEVICE
3) Press [EXECUTE] key, and press [YES] key.
Data transfer selected in the procedure 2) is performed.
When the operation is completed normally, "COMPLETE" is
displayed. In case of an abnormal end, "ERROR" is displayed.
56-4
Purpose
Data backup
Function (Purpose)
Used to backup the JOB log data to the
USB memory.
Section
Operation/Procedure
1) Insert the USB memory into the main unit.
2) Press [JOB LOG EXPORT] key.
3) Press [EXECUTE] key, and press [YES] key.
Data transfer selected in the procedure 2) is performed.
When the operation is completed normally, "COMPLETE" is
displayed. In case of an abnormal end, "ERROR" is displayed.
EEPROM  HDD Transfer from EEPROM to HDD
HDD  EEPROM Transfer from HDD to EEPROM
PWB Type Content NOTE
Controller Machine serial No.
Product key information
Various counter Copy counter/FAX
send counter etc.
Trouble history
PCU Machine serial No.
Various counter Maintenance counter
Machine adjustment execute
history
Trouble history
SCU Various counter Maintenance counter
Trouble history
Classifi-
cation
Content NOTE
Japanese
FEP
User dictionary
Job end list Job end list display data
(The image send series include
the preserved job list.)
Log Job log Read from WEB is
enable.
New N/A • Print history information
• JAM history information
• Trouble history information
• Same position continuous jam
count value
• Charging information
• Life information
Operation
manual
E-manual
