MX-M264U SIMULATION 6 – 68
64
64-2
Purpose
Operation test/check
Function (Purpose)
Test print. (Self print) (Monochrome mode)
Section
Operation/Procedure
1) Set the print conditions.
Select an item to be print condition with scroll keys.
Change the set values with 10-key.
2) Press [EXECUTE] key.
The test print (self print) is performed.
Print pattern of Item A
Item/Display Content Setting range Default value
A PRINT PATTERN
(1, 2, 17 - 19)
Print pattern specification
(* For details, refer to the description below.)
1 - 58
(Printable only 1, 2, 17 - 19)
1
B DOT1 (DOT1>=2 IF A: 2) Setting of print dot number (M parameter)
(Self print pattern: m by n)
1-255
(Pattern 2, 11: 2-255 except above: 1-255)
1
C DOT2 (DOT1>=2 IF A:2) Setting of blank dot number
(N parameter) (Self print pattern: m by n)
0-255
(Pattern2, 11: 2-255 except above: 0-255)
254
D DENSITY (DOT1>=2 IF A:2) Used to specify the print gradation. 1-255 255
E MULTI COUNT Number of print 1 - 999 1
F EXPOSURE
(2 - 8 IF A: 17 - 19)
THROUGH Exposure mode
specification
No process (through) 1-8
(Pattern 17-19: 2-8
except above: 1-8)
18
(STANDARD
DITHER)
CHAR/PIC Text/Printed Photo 2
CHAR/PRPIC Text/ Photograph 3
CHAR Text 4
PRINT PIC Printed Photo 5
PRINT PAPER Photograph 6
MAP Map 7
STANDARD DITHER Dither without correction 8
G PAPER MFT Tray selection Manual paper feed 1 - 5 1 2
(CS1)
CS1 Tray 1 2
CS2 Tray 2 3
CS3 Tray 3 4
CS4 Tray 4 5
H DUPLEX YES Duplex print
selection
Yes 0 - 1 0 1
(NO)
NO No 1
I PAPER TYPE PLAIN Paper type Standard paper 1 - 6 1 1
(PLAIN)
HEAVY Heavy paper 2
OHP OHP 3
ENVELOPE Envelope 4
Pattern No. Content
Pattern generating
section
NOTE
1 Grid pattern LSU-ASIC • Print is started at 4mm from the paper lead edge.
• Writing regardless of void. The first one is fixed to LD1.
2 Dot print –
17 All background (halftone) Halftone (IMG-ASIC
rear process)
–
18 256 gradations pattern
(Other dither)
• 16 gradations are printed in the main scan direction, and the following 16 gradations
are printed in the next line. (16 x 16 patch print)
• Printing is started at 5mm from the paper lead edge.
• Printing is made from 255 gradation, and 0 - 254 gradations are printed.
19 256 gradations pattern
(For text dither)
–
