MX-M264U DISASSEMBLY AND ASSEMBLY 10 – 25

(1) Transport roller 2, Transport roller 3,

Paper exit roller

1) Clean the transport roller 2, the transport roller 3, and the

paper exit roller

(2) Scan plate

1) Clean the scan plate.
