MX-M264U SIMULATION 6 – 6
56 1 Used to transport data between HDD - MFP PWB SRAM/EEPROM. (Used to repair the PWB.)
2 Used to backup the data in the EEPROM. SD Card, and HDD (including user authentication data and
address data) to the USB memory. (Corresponding to the device cloning and the storage backup.)
3 Used to backup the document filing data to the USB memory.
4 Used to backup the JOB log data to the USB memory.
5 Used to import the SIM22-6 data to a USB memory in the TEXT format.
11 Used to save the data in the SD card to the HDD temporarily.
12 Used to copy the SD card data saved temporarily in the HDD with SIM56-11 to the machine.
60 1 Used to check the memory operations (read/write) of the MFP PWB.
61 1 Used to check the LSU polygon motor rotation and laser detection. LSU
3 Used to set the laser power
62 1 Used to format the hard disk. (HDD: Excluding the Operation manual and the watermark data)
2 Used to check read/write of the hard disk (partial).
3 Used to check read/write of the hard disk (all areas).
6 Used to perform the self diagnostics of the hard disk.
7 Used to print the hard disk self diagnostics error log.
8 Used to format the hard disk. (HDD: Excluding the Operation Manual, the watermark data, and the system
area)
10 Used to clear the job completion list data.
11 Used to delete the document filing data.
12 Used to set Enable/Disable of auto format in a hard disk trouble.
13 Used to format the hard disk. (Operation Manual, watermark data only)
14 Used to initialize (remake) only the database file of the HDD. HDD
63 1 Used to display the shading correction result. Scanner
2 Used to perform shading.
3 Used to perform scanner (CCD) color balance and gamma auto adjustment. Scanner
4 Used to display the SIT chart patch density.
5 Used to perform the scanner (CCD) color balance and gamma default setting.
64 2 Test print. (Self print) (Monochrome mode)
4 Printer test print. (Self print)
5 Printer test print. (Self print) (PCL)
6 Printer test print. (Self print) (PS)
65 1 Used to adjust the touch panel (LCD display section) detection coordinates. Operation panel section
2 Used to display the touch panel (LCD display section) detection coordinates.
5 Used to check the operation panel key input.
66 1 Used to display the FAX-related soft SW (2 - 150) on the LCD to allow changing the soft SW while checking
with the LCD.
FAX
2 Used to enter a country code and set the default value for the country code. FAX
3 Used to check read/write of the EEPROM and the SDRAM on the MODEM controller and display the result. FAX
4 Used to send the selected signals to the line and the main unit speaker. (Send level: max.) FAX
5 Used to send the selected signal to the line and the main unit speaker. (Send level: Soft SW setting)
(For the kinds of send signals, refer to SIM66-04.)
FAX
6 Used to print the confidential registration check table (BOX NO., BOX name, passcode.
(If there is no confidential registration, no print is made.)
FAX
7 Used to output all image data saved in the image memory. (Confidential data are also outputted.) FAX
8 Used to send the selected sound messages to the line and the speaker. (Send level: Max.) FAX
9 Used to send the selected sound message to the line and the speaker. (Send level: Soft SW setting)
* For details of sound messages, refer to the sound message table of SIM66-08.
FAX
10 Used to clear the FAX and image send image data. (The confidential data are also cleared.) FAX
11 Used to send the selected signal at 300bps to the line and the speaker. (Send level: Max.) FAX
12 Used to send the selected signal at 300bps to the line and the speaker. (Send level: Soft SW setting)
* For the kings of send signals at 300bps, refer to SIM66-11, 300bps send signal table.
FAX
13 Used to register dial numbers for SIM66-14/15/16, Dial test. (Up to 20 digits can be registered.) FAX
14 Used to execute the dial pulse (10PPS) send test and to adjust the make time. FAX
15 Used to execute the dial pulse (20PPS) send test and to adjust the make time. FAX
16 Used to execute the DTFM signal send test and to adjust the send level. FAX
17 Used to send the DTMF signal to the line and the speaker. (Send level: Max.) FAX
18 Used to send the DTMF signal to the line and the speaker. (Send level: Soft SW setting) FAX
21 Used to print the selected items (system error, protocol monitor). FAX
22 Used to set the handset sound volume. (This simulation can be executed even though the handset setting
is set to NO. When, however, the handset is not installed, the sound volume cannot be checked.)
(Japan model only)
FAX
24 Used to clear the FAST save data. FAX
29 Used to initialize the telephone book data (the one-touch registration table, the FTP/Desktop expansion
table, the group expansion table, the program registration table, the interface memory box table, the meta
data, InboundRouting, and the DocumentAdmin table).
FAX
30 Used to display the TEL/LIU status change, The display is highlighted by status change. FAX
31 Used to set ON/OFF the port for output to TEL/LIU. FAX
32 Used to check the fixed data received from the line and to display the result. FAX
33 Used to execute detection of various signals with the line connected and to display the detection result.
When a signal is detected, the display is highlighted.
FAX
Main Sub Functions Section
