Sharp MX-M264N Service Manual

MX-M264U SIMULATION 6 – 9
3-10
Purpose
Adjustment
Function (Purpose)
Used to adjust the finisher.
Section
Finisher
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key. (The set value is saved.)
Inner finisher (MX-FN23)
4
4-2
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the sen-
sors and detectors in the desk, and the
control circuit of those.
Section
Desk
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The code names of the sensors and the detectors which are active
are highlighted.
Desk
4-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the loads
in the desk, and the control circuit of those.
Section
Desk
Operation/Procedure
1) Select the load item that is required to operation check with the
touch panel key.
2) Press [EXECUTE] key.
The selected load performs the operation.
When [EXECUTE] key is pressed, the operation is terminated.
Desk
4-5
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the paper
feed desk paper transport clutch (DTRC).
Section
Desk
Operation/Procedure
Check the ON operation
Press the button of the code name for checking the ON operation.
Checking is started. When the operation is normal, the button on
the display is highlighted. When it is abnormal, the button is not
highlighted.
Check the OFF operation
Press the highlighted button which is ON.
When the operation is normal, the highlighted button on the display
returns to the normal display. When it is abnormal, the highlighted
display is maintained.
Item/Display Content
Setting
range
Default
value
Change when the adjustment value is
increased or decreased
Change when the adjustment
value is changed by 1
A FPAM ADJUST Paper alignment width
adjustment
40 - 60 50 When the adjustment value is increased, the
width of the alignment plate F/R during
alignment operation is decreased.
When the adjustment value is decreased, the
width of the alignment plate F/R during
alignment operation is increased.
0.419mm
B FDRLM ADJUST Paper exit roller descending
position adjustment
40 - 60 50 When the adjustment value is increased, the
descending position of the paper exit roller is
shifted to the compression side.
When the adjustment value is decreased, the
descending position of the paper exit roller is
shifted to the decompression side.
0.13mm
Display Content
C3PFD Cassette 3 paper entry sensor
C3LUD Cassette 3 paper upper limit sensor
C3PED Cassette 3 paper empty sensor
C3SS Cassette 3 installation sensor
DSW_C3 Cassette 3 door open/close sensor
C4PFD Cassette 4 paper entry sensor
C4LUD Cassette 4 paper upper limit sensor
C4PED Cassette 4 paper empty sensor
C4SS Cassette 4 installation sensor
DSW_C4 Cassette 4 door open/close sensor
Display Content
CPFM Desk motor
PTRC1 Desk vertical transport clutch
C3LUM Cassette 3 lift-up motor
C3PUC Cassette 3 paper feed clutch
C3PUS Cassette 3 paper feed solenoid
C4LUM Cassette 3 lift-up motor
C4PUC Cassette 4 paper feed clutch
C4PUS Cassette 4 paper feed solenoid
Button Content
DTRC Desk transport clutch
