Sharp MX-M264N Service Manual

MX-M264U SIMULATION 6 – 13
8-6
Purpose
Operation test/check/adjustment
Function (Purpose)
Used to check the output of the transfer
charger output voltage.
Section
Process (Transport)
Operation/Procedure
1) Select a target item to be adjusted with scroll keys.
2) Enter the set value with 10-key.
3) Press [EXECUTE] key.
The set value is saved and the voltage corresponding to the
set value is output for 30 sec.
When [EXECUTE] key is pressed, the output is terminated.
Item/Display Content
Setting
range
Default value
26cpm
machine
31cpm
machine
35cpm
machine
A +V1 F Transfer
bias
reference
value
Standard
paper
W Between
papers
Single A-1: W, +V1 F (Between
papers), Standard paper
front surface
(Single/Duplex)
0 - 255 5 5 5
B +V1 R Duplex A-2: W, +V1 R (Between
papers), Standard paper
back surface (Duplex)
0 - 255 5 5 5
C +V2 F Paper Single A-3: W, +V2 F, Standard
paper front surface
(Single/Duplex)
0 - 255 14 18 20
D +V2 R Duplex A-4: W, +V2 R, Standard
paper back surface
(Duplex)
0 - 255 12 16 14
E +V1 S-F Standard
paper
N1jp Between
papers
Single B-1: N1jp, +V1 S-F
(Between papers),
Standard paper front
surface (Single/Duplex)
0 - 255 5 5 5
F +V1 S-R Duplex B-2: N1jp, +V1 S-R
(Between papers),
Standard paper back
surface (Duplex)
0 - 255 5 5 5
G +V2 S-F Paper Single B-3: N1jp, +V2 S-F,
Standard paper front
surface (Single/Duplex)
0 - 255 14 18 20
H +V2 S-F Duplex B-4: N1jp, +V2 S-F,
Standard paper back
surface (Duplex)
0 - 255 14 18 20
I +V1 XS-F Standard
paper
N2jp Between
papers
Single C-1: N2jp, +V1 XS-F
(Between papers),
Standard paper front
surface (Single/Duplex)
0 - 255 5 5 5
J +V1 XS-R Duplex C-2: N2jp, +V1 XS-R
(Between papers),
Standard paper back
surface (Duplex)
0 - 255 5 5 5
K +V2 XS-F Paper Single C-3: N2jp, +V2 XS-F,
Standard paper front
surface (Single/Duplex)
0 - 255 14 18 20
L +V2 XS-R Duplex C-4: N2jp, +V2 XS-R,
Standard paper back
surface (Duplex)
0 - 255 14 18 20
M +V1 THICK Heavy
paper
>LTR Between papers D-1: > LTR, +V1 THICK
(Between papers),
Heavy paper
0 - 255 5 5 5
N +V2 THICK Paper D-2: > LTR, +V2 THICK,
Heavy paper
0 - 255 10 14 16
O +V1 THICK S LTR Between papers E-1:  LTR, +V1 THICK S
(Between papers),
Heavy paper
0 - 255 5 5 5
P +V2 THICK S Paper E-2:  LTR, +V2 THICK
S, Heavy paper
0 - 255 12 14 16

Sharp MX-M264N Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	26 ppm
Max Print Resolution	600 x 600 dpi
Standard Paper Capacity	1100 sheets
Max Paper Capacity	2100 sheets
Automatic Duplexing	Yes
ADF Capacity	100 sheets
Scan Resolution	600 x 600 dpi
Copy Speed	26 cpm
Copy Resolution	600 x 600 dpi
Connectivity	Ethernet, USB
