Sharp MX-M264N Service Manual

MX-M264U SIMULATION 6 – 14
9
9-2
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the sen-
sors and detectors in the paper reverse
section (duplex section) and its control cir-
cuit.
Section
Duplex
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The code names of the sensors and the detectors which are active
are highlighted.
9-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the load in
the paper reverse section (duplex section)
and its control circuit.
Section
Duplex
Operation/Procedure
1) Select the item to be operation checked with the touch panel
key.
2) Press [EXECUTE] key.
The selected load performs the operation.
When [EXECUTE] key is pressed, the operation is terminated.
Q +V1 THIN Transfer
bias
reference
value
Thin
paper
>LTR Between papers D-7: > LTR, +V1 THIN
(Between papers),
Thin paper
0 - 255 5 5 5
R +V2 THIN Paper D-8: > LTR, +V2 THIN,
Thin paper
0 - 255 12 18 20
S+V1 THIN S LTR Between papers E-7:  LTR, +V1 THIN S
(Between papers),
Thin paper
0 - 255 5 5 5
T +V2 THIN S Paper E-8:  LTR, +V2 THIN S,
Thin paper
0 - 255 12 18 20
U +V1 LABEL Label
sheet
>LTR Between papers D-3:  LTR, +V1 LABEL
(Between papers),
Label sheet
0 - 255 5 5 5
V +V2 LABEL Paper D-4: > LTR, +V2 LABEL,
Label sheet
0 - 255 12 18 20
W +V1 LABEL S LTR Between papers E-3:  LTR, +V1 LABEL
S (Between papers),
Label sheet
0 - 255 5 5 5
X +V2 LABEL S Paper E-4:  LTR, +V2 LABEL
S, Label sheet
0 - 255 12 14 16
Y +V1 OHP OHP >LTR Between papers D-5: > LTR, +V1 OHP
(Between papers), OHP
0 - 255 5 5 5
Z +V2 OHP Paper D-6: > LTR, +V2 OHP,
OHP
0 - 255 8 14 16
AA +V1 OHP S LTR Between papers E-5:  LTR, +V1 OHP S
(Between papers), OHP
0 - 255 5 5 5
AB +V2 OHP S Paper E-6:  LTR, +V2 OHP S,
OHP
0 - 255 12 18 20
AC +V1 POSTCARD Postcard/
Envelope
>100mm Between papers D-9: > 100mm, +V1
POSTCARD (Between
papers),
Postcard/Envelope
0 - 255 5 5 5
AD +V2 POSTCARD Paper D-10: > 100mm, +V2
POSTCARD,
Postcard/Envelope
0 - 255 16 26 26
AE +V1 POSTCARD S 100mm Between papers E-9:  100mm, +V1
POSTCARD S (Between
papers),
Postcard/Envelope
0 - 255 5 5 5
AF +V2 POSTCARD S Paper E-10:  100mm, +V2
POSTCARD S,
Postcard/Envelope
0 - 255 16 26 26
Item/Display Content
Setting
range
Default value
26cpm
machine
31cpm
machine
35cpm
machine
Display Content
APPD1 ADU paper transport detector 1
Display Content
ADUM ADU motor
