Chapter 3: Specifications
SPD-M20A Service Manual
9
Chapter 3: Specifications
3.1 Specifications
3.1.1 Performance specifications
Light source
D2 & W lamp
Wavelength range
190 ~ 800 nm
Wavelength performance
1 nm
Element number
512
Element resolution
1.2 nm
Slit width
Can be switched between a 1.2 nm and 8 nm slit
Noise level
0.3  10
-5
AU ( 250 nm, 600 nm blank cell time constant: 2 sec)
Drift
<0.5  10
-3
AU/h ( 250 nm, 600 nm blank cell time constant: 2 sec)
3.1.2 Flow cell (standard)
Cell volume
10 l
Cell optical path length
10 mm
Cell withstand pressure
12 MPa (120 kgf/ cm
2
)
Material in contact with liquid
SUS316L, quartz, PFA
3.1.3 Safety Features
Thermistor
100 C (lamp housing surface)
Temperature fuse
116 C (installed on power supply board cooling fan)
Leak sensor
Leak check via leak sensor
Micro switch
Switches off lamp when lamp protection cover is removed
3.1.4 Detector main unit
Interface
TCP/IP
RS-232C
Analog output 4 ch
External dimensions (W  D  H
mm)
260  140  420 (width  height  depth)
Weight
12 kg
Operating temperature/humidity
range
(See the note below)
4 ~ 35 C / 45% ~ 85% (no condensation)
Power source voltage (V)
Categorized as follows according to product part number.
P/N 228-45005-31
100 10 VAC 150 VA (AC50/ 60Hz)
P/N 228-45005-32
120 10 VAC 150 VA (AC50/ 60Hz)
P/N 228-45005-38
220 ~ 230 20 VAC or 240 20 VAC selectable150 VA (AC50/
60Hz)
NOTE
 The operating temperature range of the entire system is influenced by the
operating temperature range of the personal computer or printer.
 For the operating temperature ranges of the personal computer and printer, see
the respective instruction manuals.
