Shimadzu SPD-M20A User Manual

80
< High Sensitivity UHPLC Optional Flow cell >
No.
P/N
Part Name
Remark
1
Gasket
228-35097-01
For Fast Cell ID 1.0
1
Gasket
228-35097-05
For Fast Cell ID 0.8
2
Lens
228-14572
3
Cell window
228-18058
4
Lens Fixing Screw
ASSY
228-40239-91
5~7
Inlet tubing ASSY
228-45609-41
Mail nut and Ferrule are attached.
6
Mail nut,0.8MN-M4
228-42605
7
Ferrule,0.8F
228-40997-10
8
Outlet tubing Kit
228-45609-94
With connector
9
Heater ASSY
228-40189-43
43: with poly switch
10
Coupling 1.6C-0.4
228-16004-13
Coupling for Outlet tubing
11
Male nut,PEEK
228-18565
Male nut for Coupling
Light
⑤
⑧
④
②
①
①
③
④
⑥
⑦
⑥
⑦
