Shimadzu SPD-M20A User Manual

89
52
228-41963-91
CABLE, FLAT 1
1
53
228-41828-91
CABLE, CPU-CELL
1
55
070-02832-91
Lock screw, JFS-4S-B1W
2
70
020-46147
Screw, SUS sems P2 M4X8
4
71
020-46534
Screw, SUS sems P3 M3X6
17
72
020-46543
Screw, SUS sems P3 M3X35
6
73
020-46546
Screw, SUS sems P3 M4X6
8
74
020-05124
Screw, SUS pan head M2.5X8
1
75
023-77025
Washer, SUS spring 2 M2.5
1
76
020-37511
Screw, SUS binding head M4X6
4
77
023-04130
Nut, SUS #3 M3
2
78
020-46547
Screw, SUS sems P3 M4X8
2
79
020-12105
Screw, SUS countersunk M3X8
2
80
017-20050-32
Adhesive, 425 20G
0.02
81
072-02004-21
Fuse, 218 3.15
2
9.4 Temperature Controlled Cell ASSY (P/N 228-42593)
Temperature Controlled Cell ASSY
Parts Table
No.
P/N
Part Name
Qty
1
228-42592-91
Cell Sub ASSY
1
2
228-42591
Cell plate
1
3
228-37445
Inner cover, cell
1
4
228-37446
Outer cover, cell
1
5
228-38390-91
Cell fixing screw ASSY
2
10
228-35097-03
Gasket, 6X3X0.1
2
11
228-14572
Lens (R4, RD6)
1
