Chapter 6: Maintenance and Adjustments
SPD-M20A Service Manual
56
3) The contents of the menu for service Function are as follows.
The contents of function menu
Menu name
Function
Sensor Check
The check of leak sensor of operation is performed.
Set Threshold
Threshold setup is performed.
Calibration
It is used at the time pf adjustment of a leak sensor. (refer 6.19.1.1.)
< Instrument Information >
1) The menu for PDA Utility service menu.
2) The Instrument Information button is pushed.
The Instrument Information window is displayed.
Serial number and manufact date can be inputted on this screen.
ROM Version, ExposureTime, and W Lamp Voltage are automatically changed after
upgrade.
