Shimadzu SPD-M20A User Manual

81
< Mechanical parts list >
No.
P/N
Part Name
Remark
1
228-42566
Fix ture
Plate which fixes "Coupling1.6C"
2
037-02820-55
Low let screw (white)
Screw which fixes a plate
3
228-45087
NS latch
Door catch parts
< Electrical System Parts List >
No.
P/N
Part Name
Remark
1
228-43200-98/48
Panel ASSY (SPD-M20A)
Left panel (including LED printed circuit board and
hinge)
2
228-43040-91
Light panel ASSY, STD
Right panel
3
228-45611-91
Main frame M20A ASSY
Panel retention frame
4
228-41820-91/41
PCB ASSY, PDA-CPU
CPU printed circuit board
5
228-41800-91/41
PCB ASSY, PDA-POWER
Power supply printed circuit board
6
072-02004-16
Fuse, 218 001
Protection fuse on power supply printed circuit
board
7
228-42917-91/42
Transformer SW M20 ASSY
Transformer SW M20 ASSY
8
228-42589-92
Fan
For lamp cooling (center of instrument)
9
228-42589-91
Fan
Controller cooling (At rear of instrument)
10
228-42525-91/41
Microswitch ASSY
Lamp cover sensor
11
228-37260-91/41
PCB, LC2K-CMD1 Assy
Connector printed circuit board for temperature
controlled cell
12
228-39247-92
Link sensor ASSY, 700mm
13
072-02004-21
Fuse, 218 3.15AT
Fuse for inlet filter
14
228-25044-93/43
Sensor ASSY
For shutter ASSY
15
228-53010-41
PCB,EEPROM 32K
8.3 Optional List
No.
P/N
Name
Remarks
1
228-45605-92/42
Temperature controlled semi-micro cell
2
228-34187-91
Inert cell
3
228-34188-91
Fraction collection cell (fixed length cell)
path length: 0.5 mm
4
228-34189-91/41
Fraction collection cell (Variable length cell)
path length: 0.5 mm
5
228-34189-92/42
Fraction collection cell (Variable length cell)
path length: 0.2 mm
6
228-34189-93/43
Fraction collection cell (Variable length cell)
path length: 0.1 mm
7
228-25293-93
Semi-micro cell
8
228-45618-49
Fast Cell for SPD-M20A, ID 1.0
9
228-45618-46
Fast Cell for SPD-M20A, ID 0.8
Custom-made item
10
228-39306-91
Analog cable (RCA jack cable)
11
228-42622-91
Air filter ASSY
