Shimadzu SPD-M20A - Power Board Diagram

90
12
228-40239-91
Lens fixing screw ASSY
2
13
228-18058
Cell window
1
14
228-40189-43
Heater ASSY
1
15
228-41049
Sheet, heat conducting
1
16
228-40503-01
GND plate, cell
1
17
060-49746-16
Bushing, B-24 for TR
1
18
228-40998-10
Coupling, 1.6-0.8C
2
19
228-40996
Male nut 0.8MN
2
20
228-40997-10
Ferrule, 0.8F 316L
2
21
020-46635
Screw, SUS sems P4 M3X8
2
22
020-12104
Screw, SUS flat head M3X6
1
23
020-46634
Screw, SUS sems P4 M3X6
3
25
020-03144
Screw, PA pan head M3X8
4
30
036-10204
O-ring, 1A P6
2
100
228-42593
Temperature controlled cell ASSY
AR
101
228-40179
Test specifications, temperature controlled cell
AR
102
228-40180
Packing specifications, temperature controlled cell
AR
103
228-34290-93
Cell assembling jig
AR
