Chapter 5: Assembly and Disassembly of Parts

SPD-M20A Service Manual

The fuses can be replaced and the power supply voltage can be switched by

opening the lid of the receptacle on the rear panel of the main unit with a slotted

screwdriver.

NOTE

 For details regarding fuse replacement and power supply voltage switching, see

the Instruction Manual "8.7 Fuse Replacement, "9.1.3 Power Supply Connection".

Voltage selector

Fuse holders
