Shimadzu SPD-M20A User Manual

86
8
228-33184-92
M2 ASSY
1
9
228-42519-91
Slit ASSY, SH2
1
10
228-33187-92
GR ASSY, M20A
1
11
228-42520-91
PDA ASSY
1
12
228-42572
Lamp housing, D2
1
13
228-33195
Plate, D2
1
14
228-33823
Spacer, D2
3
15
228-34016
LAMP D2
1
16
228-33353
Guide, fin D2
1
17
205-82702-01
Window plate, W (12) -G
1
18
228-42521
Plate, cell chamber
1
19
228-14534
Positioning pin
2
22
228-42522-91
Thermistor ASSY
1
23
228-42611-91
Lamp cap ASSY
1
24
228-42607-04
Sponge, left
1
25
228-44280
Sponge, back
1
26
228-44279
Plate, left
1
27
072-60333-03
Clip, wire SD-15
2
30
026-02085
SUS spring pin 4X10
1
31
037-30128-16
Nut, C-440-L
3
44
037-38881-13
Spacer, CX-403
3
45
228-33686
Spacer, 12X10
1
48
017-20075-05
Adhesive, LP454 GL
0.02
49
017-20122-01
Adhesive, Araldite standard
0.1
50
020-46650
Screw, SUS sems P4 M4X8
18
51
020-46652
Screw, SUS sems P4 M4X12
3
52
020-46534
Screw, SUS sems P3 M3X6
4
53
020-46554
Screw, SUS sems P3 M4X30
3
54
023-04040
Nut, SUS #1 M4
3
55
023-66040
Washer, SUS plain mini 4
1
56
023-77040
Washer, SUS spring 2 M4
3
57
020-46134
Screw, SUS sems, P2 M3X6
1
58
020-05141
Screw, SUS pan head M3X25
1
59
020-05158
Screw, SUS pan head M4X50
1
62
023-04130
Nut, SUS #3 M3
1
67
Nut
SUS #1 M6
1
68
023-66150
Washer, SUS flat M5
3
