SICK deTec4 User Manual

Table 54: Response time of a single device
1)
Protective field
hei
ght in mm
Response time in ms
Resolution 14 mm Resolution 30 mm
Uncoded Code 1 or c
ode 2 Uncoded Code 1 or code 2
300 11 16 9 12
450 12 19 10 14
600 13 22 10 15
750 13 25 11 16
900 14 28 11 17
1050 15 31 11 18
1200 16 34 12 20
1350 17 37 12 21
1500 18 40 13 22
1650 19 42 13 23
1800 20 45 13 24
1950 21 48 14 25
2100 22 51 14 27
1)
The values apply to individual devices without configured Smart Box Detection.
Response time for a cascade of two devices
b
C
alculate the response time of the cascade using the following formula:
t
C
= t
H
+ t
G1
Where:
°
t
C
= r
esponse time of the cascade
°
t
H
= response time of the device used as host, see table 54
6)
°
t
G1
= response time of the device used as guest 1, see table 54
Response time for a cascade of three devices
b
C
alculate the response time of the cascade using the following formula:
t
C
= t
H
+ t
G1
+ t
G2
Where:
°
t
C
= r
esponse time of the cascade
°
t
H
= response time of the device used as host, see table 54
7)
°
t
G1
= response time of the device used as guest 1, see table 54
8)
°
t
G2
= response time of the device used as guest 2, see table 54
13.4 Power consumption
Table 55: Power consumption for sender and receiver
Protective field
hei
ght in mm
Typical power consumption for
sender in W
Typical power consumption for
receiver in W
1) 2)
Resolution
14 mm
Resolution
30 mm
Resolution
14 mm
Resolution
30 mm
300 1.42 1.23 3.43 3.23
450 1.51 1.31 3.60 3.30
6)
T
he response time of the host within the cascade is t
C
- 6 ms.
7)
The response time of the host within the cascade is t
C
– 12 ms.
8)
The response time of guest 1 within the cascade is t
C
– 6 ms.
TECHNICAL DATA 13
8021645/1EB0/2022-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4
145
Subject to change without notice
