SICK deTec4 User Manual

Complementary information
T
he safety light curtain must be supplied with voltage to enable communication with an
IO-Link master via the IO-Link connector.
Further topics
•
"A
ccessories", page 153
3.2.17 Near Field Communication (NFC)
Overview
T
he receiver of the safety light curtain has an integrated NFC interface for transmitting
diagnostic data of the protective device to an NFC-capable device.
The integrated NFC interface is intended for temporary use.
Diagnostic data
T
he following diagnostic data can be displayed in an NFC-capable device:
•
Device-specific information of the protective device, e.g. name, serial number, type
code
•
Information on configuration, e.g. whether the restart interlock is activated
•
Current status of the protective device, e.g. status of the OSSDs, quality of the
alignment
•
Error diagnostics with specification of the error code, error description, diagnostic
LED and error correction
An NFC-capable antenna is integrated behind the front screen of the safety light curtain
for transmitting the data. The area is marked with the NFC-symbol.
Figure 4: NFC symbol
1
)
To be able to call up information for diagnostics and configuration, you need an NFC-
capable device, e.g. a smartphone and the app provided by SICK.
b
Hold the NFC-capable mobile device near the marked NFC-area on the lower end
of the receiver to call up the diagnostic data.
3.2.18 System plug
Overview
T
he following system plugs are available for the safety light curtain:
•
SP1 system plug
•
SP2 system plug
The system plugs are available in the following versions:
•
System plug with 5-pin system connection
•
System plug with 8-pin system connection
•
System plug with 5-pin system connection and 5-pin extension connection
•
System plug with 8-pin system connection and 5-pin extension connection
Functional scope
T
he system plugs differ in range of functions.
1)
T
he N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries.
PRODUCT DESCRIPTION 3
8021645/1EB0/2022-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4
17
Subject to change without notice
