15.6.5 Deflector mirror PNS125 - ordering information
Table 88: Ordering information, deflector mirror PNS125
Mirror length in mm Max. protective field
hei
ght in mm
Type code Part number
340 300 PNS125-034 1019425
490 450 PNS125-049 1019426
640 600 PNS125-064 1019427
790 750 PNS125-079 1019428
940 900 PNS125-094 1019429
1090 1050 PNS125-109 1019430
1240 1200 PNS125-124 1019431
1390 1350 PNS125-139 1019432
1540 1500 PNS125-154 1019433
1690 1650 PNS125-169 1019434
1840 1800 PNS125-184 1019435
1990 1950 PNS125-199 1092964
2140 2100 PNS125-214 1092965
15.7 Mirror columns
Table 89: Ordering information, mirror columns
Column height Mirror length Type code Part number
1,281.5 mm 1,082 mm PM3C13-00030000 1043453
1,569 mm 1,382 mm PM3C15-00030000 1077525
1,716.5 mm 1,532 mm PM3C17-00030000 1043454
2,016.5 mm 1,682 mm PM3C19-00030000 1043455
2,216.5 mm 1,832 mm PM3C20-00030000 1043456
2,269 mm 1,985 mm PM3C22-00030000 1093216
2,419 mm 2,132 mm PM3C24-00030000 1093217
Complementary information
Ob
serve the information on deflector mirrors, particularly on changing the scanning
range.
Further topics
•
"D
eflector mirrors", page 160
15.8 Device columns
Table 90: Ordering information for device columns
Column height Max. installation
len
gth
Type code Part number
985 mm 965 mm PU3H96-00000000 2045490
1185 mm 1165 mm PU3H11-00000000 2045641
1285 mm 1265 mm PU3H13-00000000 2045642
1570 mm 1550 mm PU3H15-00000000 2068813
1740 mm 1720 mm PU3H17-00000000 2045643
15 ACCESSORIES
162
O P E R A T I N G I N S T R U C T I O N S | deTec4 8021645/1EB0/2022-04-28 | SICK
Subject to change without notice
