SICK deTec4 User Manual

Part Type code Part number
Female connector, straight, 15 m cable,
s
traight male connector
YF2A18-150UA5M2A18 2104374
Table 76: Ordering information for connection cable (replacement of C4000 with deTec4)
9)
Part Type codes Part number
M12 connection cable, 5-pin to M12, 5-pin YF2A14-C20UB3M2A14 2096013
Connection cable, M12, 8-pin to M12, 8-pin DSL-6108GM25034KM1 2034865
Connection cable M12 8-pin to M26, 7-pin DSL-6130GM25034KM1 2081443
Connection cable M12 8-pin to M26, 12-pin DSL-6129GM25034KM1 2081442
Connection cable M12 8-pin to M26, 12-pin DSL-6129GM25034KM7 2112706
Table 77: Ordering information for distributor
Part Type code Part number
T distributor, 5-pin DSC-1205T000025KM0 6030664
T distributor, 8-pin DSC-1208T000025KM0 6058647
T-connector with pushbutton for laser alignment aid, M12, 5-pin 2077933
4
5
3
2
1
S
1
4
5
3
2
1
4
5
3
2
1
System
ReceiverSender
Figure 71: Internal circuitry: T-connector with pushbutton for laser alignment aid (5-pin)
Table 78: Ordering information for the connector
Part Part number
Muting connector 2092758
IO-Link connector 2092757
Table 79: Connection modules ordering information
Part Part number
SiLink2 master 1061790
Table 80: Sensor Integration Gateway ordering information
Part Part number
SIG200 REST-API 1102605
SIG200 PROFINET 1089794
SIG200 Ethernet/IP 1089796
9)
Ambient oper
ating temperature: Down to −30° C with fixed installation.
15 A
CCESSORIES
158
O P E R A T I N G I N S T R U C T I O N S | deTec4 8021645/1EB0/2022-04-28 | SICK
