13 Technical data
13.1 Version numbers and range of functions
The table below describes the technical changes or extensions of the range of function
made t
o the device in the course of product maintenance.
The range of functions refers only to the receiver. The sender is not affected and is
compatible with the change states.
We use a three-digit version number to identify the different change states of the range
of function.
The range of functions of the device is found at the following locations:
•
On the type label: "Ident No." field
•
In the SICK Safety Assistant app via NFC: Technical data or report
•
Via IO-Link in the ISDU of the respective device (DeviceIdentRH, DeviceIdentRG1,
DeviceIdentRG2): "HcsvMajor", "HcsvMinor", "HcsvRelease" field
•
Via IO-Link in the SDD for SOPAS ET
Table 48: Version numbers and range of functions
Version number Amendments and new func‐
tions
Additional information
No version number (1.0.0) Initial device version
1.1.0 Supplement to the Smart Box
D
etectionfunction
"Smart Box Detection", page 47
13.2 Data sheet
Table 49: General system data
Minimum Typical Maximum
Protective field height, depending on
t
ype
300 mm to 2,100 mm, 150-mm steps
Resolution (detection capability),
depending on type
14 mm or 30 mm
Protective field width
1) 2) 3)
Resolution 14 mm 0.15 m ... 16 m 0.15 m ... 20 m
Resolution 14 mm (sender with
small sc
anning range)
0.15 m ... 2 m 0.15 m ... 2.5 m
Resolution 30 mm 0 m … 24 m 0 … 30 m
Protection class
4)
III (IEC 61140)
Enclosure rating
5)
IP65 (IEC 60529)
IP67 (IE
C 60529)
Supply voltage U
V
a
t the device
6) 7) 8)
19.2 V 24 V 28.8 V
Residual ripple
9)
± 10%
Synchronization Optical
Type Type 4 (IEC 61496-1)
Category Category 4 (ISO 13849-1)
Performance level
10)
PL e (ISO 13849–1)
Safety integrity level
10)
SIL 3 (IEC 61508)
SIL claim limit
10)
SILCL 3 (IEC 62061)
PFH
D
(me
an probability of a dangerous failure per hour)
11)
13 TECHNICAL DATA
140
O P E R A T I N G I N S T R U C T I O N S | deTec4 8021645/1EB0/2022-04-28 | SICK
Subject to change without notice
