14 Ordering information
14.1 Scope of delivery
Scope of delivery, sender
•
S
ender
Scope of delivery, receiver
•
R
eceiver
•
Test rod with diameter corresponding to the resolution of the safety light curtain
•
Safety note
•
Mounting instructions
•
Operating instructions for download: www.sick.com
14.2 Ordering information
Table 60: SP1 system plug ordering information
Connection type Type codes Part number
System connection (M12, 5-pin) 1000 2076832
System connection (M12, 8-pin) 1200 2076834
System connection (M12, 5-pin) and extension
connec
tion (M12, 5-pin)
1100 2076833
System connection (M12, 8-pin) and extension
connection (M12, 5-pin)
1300 2076835
Table 61: SP2 system plug ordering information
Connection type Type codes Part number
System connection (M12, 5-pin) 2000 2093097
System connection (M12, 8-pin) 2200 2093099
System connection (M12, 5-pin) and extension
connec
tion (M12, 5-pin)
2100 2093098
System connection (M12, 8-pin) and extension
connec
tion (M12, 5-pin)
2300 2093100
Table 62: Ordering information for deTec4, resolution 14 mm
Protective field
hei
ght in mm
s S
ender r Receiver
Part number Type codes Part number Type code
300 1220084 C4P-SA03011A00 1220097 C4P-EA03011C00
450 1220085 C4P-SA04511A00 1220098 C4P-EA04511C00
600 1220086 C4P-SA06011A00 1220099 C4P-EA06011C00
750 1220087 C4P-SA07511A00 1220100 C4P-EA07511C00
900 1220088 C4P-SA09011A00 1220101 C4P-EA09011C00
1050 1220089 C4P-SA10511A00 1220102 C4P-EA10511C00
1200 1220090 C4P-SA12011A00 1220103 C4P-EA12011C00
1350 1220091 C4P-SA13511A00 1220104 C4P-EA13511C00
1500 1220092 C4P-SA15011A00 1220105 C4P-EA15011C00
1650 1220093 C4P-SA16511A00 1220106 C4P-EA16511C00
1800 1220094 C4P-SA18011A00 1220121 C4P-EA18011C00
1950 1220095 C4P-SA19511A00 1220107 C4P-EA19511C00
14 ORDERING INFORMATION
150
O P E R A T I N G I N S T R U C T I O N S | deTec4 8021645/1EB0/2022-04-28 | SICK
Subject to change without notice
