LEDs Meaning
Diagnostics LEDs
1 2 3 4 5 6 7 8
O Blue O Blue
The bottommost light beam (near system plug) is
s
ynchronized.
o LED of
f. Ö LED flashes. O LED illuminates.
1)
If external device monitoring is configured and there is an EDM warning, diagnostic LED 1 flashes, while the other diagnostic LEDs 2, 3 and
4 indicate the alignment quality. If there is an error on the reset pushbutton, diagnostic LED 4 flashes, while the other diagnostic LEDs 1, 2
and 3 indicate the alignment quality.
2)
If the protective fields are very wide, there is a possibility that diagnostic LED 4 does not light up, even with optimal alignment.
11.3.2 Status indication
Overview
Dur
ing operation, the status of the safety light curtain is indicated with LEDs.
The information in the tables applies both for single devices and for every device in a
cascade.
Sender
P
osition of the LEDs: see "Sender displays", page 21.
If the sender and receiver are connected to each other by a cable, the LEDs on the
sender indicate the same status as the LEDs on the receiver during normal operation.
The STATE LED on the sender adopts the status of the OSSD LED on the receiver.
If the sender and receiver are not connected with each other, the STATE LED on the
sender lights up yellow when the sender is in operation and no faults are present.
Receiver
P
osition of the LEDs: see "Receiver displays", page 22.
Table 45: LEDs on the receiver during normal operation
LEDs End cap with inte‐
gr
ated LED
Meaning
OSSD Field Diagnostics LEDs
1 2 3 4 5 6 7 8
O
W
hite
EDM is configured.
O
White
Cascade with 1 or
w
ith 2 guest devices
is configured.
O
W
hite
Beam coding 1 or 2
is conf
igured.
O
W
hite
Restart interlock is
conf
igured.
O
W
hite
Muting or partial
blank
ing is config‐
ured.
OR
Smart Box Detection
is configured.
O
W
hite
Reduced resolution
is conf
igured.
TROUBLESHOOTING 11
8021645/1EB0/2022-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4
127
Subject to change without notice
