Table 3: Range of functions
Functions SP1 system plug SP2 system plug
Beam coding
✓ ✓
Restart interlock
✓ ✓
External device monitoring
(EDM)
✓ ✓
Application diagnostic output
✓ ✓
Cascade
✓ ✓
IO-Link
✓ ✓
Reduced resolution –
✓
Dynamic protective field width –
✓
Smart presence detection –
✓
Muting –
✓
Partial blanking –
✓
Smart Box Detection –
✓
The SP1 system plug can be used on all of the senders and receivers of a single system
or on a hos
t–guest system.
The SP2 system plug is only used on the receiver of a host system or single system. The
SP1 system plug is used on all other receivers of the guest systems and on all senders.
Prerequisites
•
T
he SP2 system plug can only be used with receivers that have the digit 1 at the
following position of their type code:
C4P-E*****1***
Using the system plugs
T
able 4: Use of SP1 system plug in a single system
SP1 system plug type code
1000 1200 1100 1300
Sender
✓
✓
1)
✓
2)
✓
1) 2)
Receiver
✓
•
Be
am coding
✓
•
Be
am coding
•
Restart inter‐
lock
•
External
device moni‐
toring
•
Application
diagnostic
output
✓
•
Be
am coding
•
Restart inter‐
lock
•
External
device moni‐
toring
•
Application
diagnostic
output
•
IO-Link
✓
•
Be
am coding
•
Restart inter‐
lock
•
External
device moni‐
toring
•
Application
diagnostic
output
•
IO-Link
✓
SP1 system plug suitable.
1)
At the sender, the 8-pin system connection is solely for the purposes of providing standardized wiring.
It is par
ticularly recommended if the 8-pin system connection at the receiver is used and the sender and
receiver are connected to each other via a T-connector.
2)
If a sender does not have an additional guest connected to it, the extension connection has no function
and must be sealed with a protective cap.
