SICK deTec4 User Manual

Table 26: SP1 system plug extension connection pin assignment (M12 female connector, 5-pin)
PIN Wire color
1)
s S
ender r Receiver
1 Brown 24 V Out (voltage supply
output)
2)
24 V Out (voltage supply
output)
2)
2 White Not assigned In1
(S
ingle system or last
guest: EDM [EDM input]
Host or first of 2 guests:
OSSD input)
3 Blue 0 V Out (voltage supply out‐
put)
0 V Out (voltage supply out‐
put)
4 Black Sync-Out (cascade synchro‐
ni
zation output)
In2
(Single system or last
guest: RES [reset pushbut‐
ton input]
Host or first of 2 guests:
OSSD input)
5 Gray MFP2 (cascade communi‐
c
ation)
MFP2
(Single system or last
guest: ADO [application
diagnostic output] / IO-Link
Host or first of 2 guests:
cascade communication)
1)
Applies to the connecting cables recommended as accessories.
2)
Only for cascading deTec devices, not suitable for connecting other devices.
Table 27: SP2 system plug extension connection pin assignment (M12 female connector, 5-pin)
PIN Wire color
1)
r R
eceiver
1 Brown 24 V Out (voltage supply
out
put)
2)
2 White In1
(Single system: EDM [EDM
input]
3)
/ muting signal 1
Host: OSSD input)
3 Blue 0 V Out (voltage supply out‐
put)
4 Black In2
(S
ingle system: RES [reset
pushbutton input] / muting
signal 2
Host: OSSD input)
5 Gray MFP2
(S
ingle system: ADO [appli‐
cation diagnostic output] /
IO-Link
Host: cascade communica‐
tion)
1)
Applies to the connecting cables recommended as accessories.
2)
Only for cascading deTec devices, not suitable for connecting other devices.
3)
When muting is configured, EDM is not possible at the extension connection.
Further topics
•
"Int
egration in electrical control", page 54
6 ELE
CTRICAL INSTALLATION
90
O P E R A T I N G I N S T R U C T I O N S | deTec4 8021645/1EB0/2022-04-28 | SICK
Subject to change without notice
