Table 16: Perceived field of view area
Working distance (mm) Horizontal (mm) Vertical (mm)
50 15.52 11.64
60 19.85 14.89
70 24.05 18.04
80 28.19 21.14
90 32.29 24.22
100 36.37 27.28
150 56.60 42.45
200 76.71 57.53
250 96.77 72.58
300 116.81 87.61
400 156.86 117.65
500 196.89 147.67
600 236.91 177.68
Table 17: Minimum resolution for Lector610
Working distance (mm) 1D code (mm) 2D code (mm)
50 0.04 0.08
150 0.16 0.25
300 0.25 0.5
600 0.5 1.0
Table 18: Minimum resolution for Lector611
Working distance (mm) 1D code (mm) 2D code (mm)
50 0.02 0.04
150 0.08 0.125
300 0.125 0.25
600 0.25 0.5
