7 CONFIGURATION OF THE DEVICE SETTINGS
42
8027311 / V1-0/2022-04|SICK
OPERATING INSTRUCTIONS|TDC-E (Telematic Data Collector)
Subject to change without notice
Allows network devices on a sensor/safety network on eth1 to establish communication
with network devices on eth0.
Possible use case Sensors that access the Internet
Used interfaces eth0, eth1
Deactivated interfaces wlan, modem
Segments 1 x bridge
1 x WAN with activated NAT
Configuration
▸
Assign eth0 to the WAN segment with NAT activated.
▸
Check responsible network area together with network
operator (DHCP client vs. manual IP and gateway setup).
▸
Assign eth1 to the bridge segment.
▸
Check with the responsible network operator (DHCP client,
DHCP server or manual IP).
Allows network devices on a sensor/safety network on eth1 to communicate with network
devices on wlan.
Possible use case Sensors that access the Internet
Used interfaces wlan, eth1
Deactivated interfaces eth0, modem
Segments 1 x bridge
1 x WAN with activated NAT
Configuration
▸
Assign wlan to the WAN segment with NAT activated.
▸
Check responsible network area together with network
operator (DHCP client vs. manual IP and gateway setup).
▸
Assign eth1 to the bridge segment.
▸
Check with the responsible network operator (DHCP client,
DHCP server or manual IP).
Allows network devices on a sensor/safety network on eth1 to communicate with network
devices on modem.
Possible use case Sensors that access the Internet
Used interfaces modem, eth1
Deactivated interfaces eth0, wlan
Segments 1 x bridge
1 x WAN with activated NAT
Configuration
▸
Assign modem to the WAN segment with NAT activated.
▸
Check responsible network area together with network
operator (DHCP client vs. manual IP and gateway setup).
▸
Assign eth1 to the bridge segment.
▸
Check with the responsible network operator (DHCP client,
DHCP server or manual IP).
Scenario 1
LAN router
Scenario 2
WLAN router
Scenario 3
modem router
