D Manufacturers
D.1 SIEB & MEYER Accessories
In the following you find all accessories for SD2M that you can order at SIEB & MEYER.
Note
Consider the information on accessories suitable for your device in the technical manu-
al.
D.1.1 Connectors of the Series SD2M
Connector kit
SIEB & MEYER article number Device variant
32299601 036228xxx
A connector kit contains mating connectors for I/O contacts, safety and logic as well
as suitable shield connection clamps (SK 8 and SK 14). All items are manufactured by
Phoenix Contact. In addition, a USB cable is provided.
Note
Submin D mating connectors for connecting the used measuring systems are not com-
prised in the connector kit.
Fiber optic connectors
SIEB & MEYER article number Description
12540102 Female connector, input (black)
12540202 Female connector, output (gray)
32022900 Cable connector (Toslink F05)
47000001 Polishing disk for optical fiber cables
47000002 Dismantling tool for optical fiber cables
47000003 Grinding paper
D.1.2 Operating Terminal
SIEB & MEYERarticle number Description
0362150 Plug-on operating terminal
0362153 Operating terminal for switch cabinet installation
32299567 Switch cabinet kit for operating terminal 0362150
D.1.3 Mains Chokes
Note
Choose the mains choke according to the expected continuous current per mains
phase.
The following mains chokes by the company Block are available from SIEB & MEYER:
SIEB & MEYERarticle number Description
13015833 Mains choke: 1 × 6 A
114 Drive System SD2M - Hardware Description 036228xxF
