117Drive System SD2M - Hardware Description 036228xxF
D.3 Line Filters by TDK & EPCOS Group
https://en.tdk.eu
▶ 3-phase line filters
▶ high attenuation
▶ partial RCD compatibility
Note
The maximum current (I
max
) must be adapted to the back-up fuses of the device.
Note
When such a line filter is used, very high leakage currents occur because of Cy > 1.5 μF.
For this reason the line filter is only to a limited extent usable with an RCD (residual cur-
rent protective device).
Depending on the SD2M device variant you can use the following line filters by TDK &
EPCOS Group:
Device variant Input power [kVA] Max. input volt-
age [V]
Max. phase cur-
rent, input [A]
Article number TDK &
EPCOS Group
(1)
173 at 400 V
AC
400 (±10 %)0362280AF
207 at 480 V
AC
480 (±10 %)
250 B84143B0250S081 (S)
B84143K0250S081 (IT)
346 at 400 V
AC
400 (±10 %)0362281BF
415 at 480 V
AC
480 (±10 %)
500 B84143B0600S081 (S)
B84143K0600S081 (IT)
(1)
(S) = standard line filter; (IT) = IT mains application without Y/capacitors
D.4 TOSHIBA - Fiber Optic Connectors
http://www.toshiba.com
D.5 WAGO Innovative Connections
http://www.wago.com
D.5.1 Shield Connection Clamps
Shield connection clamps for EMC busbar and for motor/power connection of the de-
vices
WAGO article number Description
791-111 Diameter of connectable conductor; 5 to 11 mm; height max. 47 mm;
17 mm wide (corresponds to SK 14 by Phoenix Contact)
791-117 Diameter of connectable conductor; 10 to 17 mm; height max. 63 mm;
23 mm wide (corresponds to SK 20 by Phoenix Contact)
For an alternative solution see Phoenix Shield Connection Clamps (p. 116)
