4.2 Emission of Line and Field Interferences
According to Category C4 (I > 400 A)
According to the EMC product standard DIN EN 61800-3, chapter 6 (emission of line in-
terferences), this devices meets the interference limit values of the category C4 (rated
current I > 400 A) if at least one of the below listed requirements is met.
Requirements
▶ Current higher than 400 A
▶ Voltage over 1000 V
▶ Mains supply either isolated from ground or connected to ground via a high imped-
ance („IT Networks“ according to IEC 60364-1:2005, 312.2.3)
▶ The dynamic operating behavior is limited due to filter effects.
NOTICE
Connection of line filters
→ Consider the connection instructions of the line filter manufacturer to ensure suffi-
cient filter effect.
Note
For detailed information on the used device refer to the section "Technical Data" for the
respective device.
19Drive System SD2M - Hardware Description 036228xxF
Unit Assembly Complying EMC
