115Drive System SD2M - Hardware Description 036228xxF
SIEB & MEYERarticle number Description
13015834 Mains choke: 1 × 10 A
13015835 Mains choke: 1 ×16 A
13015801 Mains choke: 3 × 16 A, uk = 3 %
13015802 Mains choke: 3 × 25 A, uk = 3 %
13015803 Mains choke: 3 × 35 A, uk = 3 %
13015804 Mains choke: 3 × 40 A, uk = 3 %
13015805 Mains choke: 3 × 50 A, uk = 3 %
13015808 Mains choke: 3 × 80 A, uk = 3 %
13015810 Mains choke: 3 × 90 A, uk = 3 %
13015811 Mains choke: 3 × 100 A, uk = 3 %
13015812 Mains choke: 3 × 180 A, uk = 3 %
13015814 Mains choke: 3 × 250 A, uk = 3 %
13015823 Mains choke: 3 × 300 A, uk = 3 %
13015825 Mains choke: 3 × 500 A, uk = 3 %
13015826 Mains choke: 3 × 630 A, uk = 3 %
Manufacturers of mains chokes:
▶ http://www.block.eu
▶ http://www.enerdoor.de
D.1.4 USB>RS232/485 Converter 050201
The USB>RS232/485 Converter can be ordered at SIEB & MEYER as an optional ac-
cessory for device configuration. This converter is developed especially for the amplifier
series SD2x. Via the converter the devices can communicate with a PC without RS232
or RS485 interface.
A short USB cable is supplied with the converter. The connection cable to the drive am-
plifiers must be ordered additionally or built by yourself with suitable length.
SIEB & MEYER article number Description
050201 USB>RS232/485 converter
K362103xxxR01 (xxx = cable
length in dm)
RS232 device connection cable to the converter 050201
For further information, refer to the document “050201 – USB>RS232/485 Converter”.
