5.2 Device Designation
e.g. 0362281BF0000 3.000
Device type Device version
0 3 6 x x x x - x x x x x x
Customized front panel
▶ 00 = SIEB & MEYER
Cooling
▶ 0 = liquid with copper tubes
Parameterization on delivery
▶ 0 = parameterized
▶ 1 = not parameterized
Performance range
Voltage class
▶ F = up to 675 V
DC
Current range
▶ see technical data
Specific type code
▶ 8x = drive amplifiers SD2M
▶ 80 = 120 kVA (AC voltage supply)
▶ 81 = 240 kVA (AC voltage supply)
▶ 82 = 145 kVA (DC-voltage supply)
▶ 83 = 345 kVA (DC-voltage supply)
Fieldbus
▶ 2 = EtherCAT
Module type
▶ 2 = series SD2x
Device version X.XXX
Serial counter. If there is no device version, 0.000 is indicated here. If a device is
exchanged by a device of another version, please contactSIEB & MEYER to check
whether the devices are compatible or not.
In addition, the device version indicates the update capability of the internal device soft-
ware, e.g. BIOS, FPGA or Firmware.
5.3 Block Diagrams
This section includes block diagrams of the SD2M series drive amplifiers. The block di-
agrams show the functional groups and connection possibilities.
21Drive System SD2M - Hardware Description 036228xxF
