Manufacturers
D.2 Phoenix Contact
http://www.phoenixcontact.com
Order key for Phoenix connectors
Pitch
3,81 = Pitch for Mini-Combicon
5,08 = Pitch for Combicon
7,62 = Pitch for PowerCombicon
10,16 = Pitch for PowerCombicon
Connector type
St = Connector without flange
STF = Connector with flange
GW = Basic housing with screw flange
Pole number
2 = 2-pole
...
Cross-section
1,5 = max. cross section 1.5 mm²
2,5 = max. cross section 2.5 mm²
4 = max. cross section 4 mm²
6 = max. cross section 6 mm²
25 = max. cross section 25 mm²
Type of housing
G = Basic housing
MC = MiniCombicon
SPTA = MiniCombicon
FMC = MiniCombicon
MSTB = Combicon
FKC = Combicon
PC = PowerCombicon
HDFK = lead-through terminal
XXXX xx/ x XXX
xxxx
=
SPC = PowerCombicon
Note
Labeled connectors can be ordered at SIEB & MEYER.
D.2.1 Surge Arrestor FLASHTRAB
Phoenix article number Description
2905469 Surge arrestor FLT-SEC-T1+T2-3C-350/25-FM: with combined PE
and N installed in one conductor (L1, L2, L3, PEN)
2905470 Surge arrestor FLT-SECT1+T2-3S-350/25-FM: with separate PE and
N (L1, L2, L3, PE, N)
D.2.2 Shield Connection Clamps
Shield connection clamps for EMC busbar and for motor/power or measuring system
connection of the devices
Phoenix article number Name Connection method Tightening torque
3025163 SK 8 Screw connection (M4) max. 0.6 Nm
3025176 SK 14 Screw connection (M4) max. 0.8 Nm
3025189 SK 20 Screw connection (M4) max. 0.8 Nm
3026463 SK 35 Screw connection (M5) 1.5 to 1.8 Nm
Alternatively you can use WAGO terminals (see WAGO Shield Connection
Clamps (p. 117)).
116 Drive System SD2M - Hardware Description 036228xxF
