Connection Examples
8.7.3
Linear Hall Encoder (1 V
pp
)
NOTICE
V
oltage (VCC) varies depending on the set measuring system
When
the
connected
measuring
system
is
operated
under
a
wrong
voltage,
it
can
be
damaged.
→
Check
that
you
have
chosen
the
right
measuring
system
in
the
software
before
connecting
.
Fig.
33:
Linear
Hall
encoder
Fig. 33: Linear Hall encoder
When this meysuring system is parameterized VCC_FB is switched to 12 V
.
70
Drive System SD2M - Hardware Description 036228xxF
69
71
