SIEB & MEYER SD2M User Manual

Fig. 16: Pressure loss/volume flow rate characteristic curve for 0362280AF and 0362282AF
0
0,5
1
1,5
2
2,5
3
3,5
4
4,5
5
5,5
6
6,5
7
7,5
0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30
Δ
p in bar
Q in l/min
Pressure loss of 0362280AF / 0362282AF water °C) ( 30
Fig. 16: Pressure loss/volume flow rate characteristic curve for 0362280AF and 0362282AF
Fig. 17: Pressure loss/volume flow rate characteristic curve for 0362281BF and 0362283BF
0
0,2
0,4
0,6
0,8
1
1,2
1,4
1,6
1,8
0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30
Δ p in bar
Q in l/min
Pressure loss 0362281BF / 0362283BF ( 30water °C)
Fig. 17: Pressure loss/volume flow rate characteristic curve for 0362281BF and 0362283BF
43Drive System SD2M - Hardware Description 036228xxF
Water Cooling
