ACCESS 9340 and 9360 Meters PMCM-9340D-0208
Chapter 6—Basic Alarms 2/2008
EN–82
• Scale Group—the scale group that applies to the test register’s
metering value (A–F). For a description of scale groups, see
“Scale Factors” on page 79.
• Alarm Type—a reference to a definition that provides details on
the operation and configuration of the alarm. For a description of
alarm types, refer to Table 6–5 on page 83.
Table 6–4 on page 82 lists the preconfigured alarms by alarm
number. Table 6–5 on page 85 lists the default alarm configurations.
Table 6–4: List of Default Basic Alarms by Alarm Number
Alarm
Number
Alarm Description
Abbreviated
Display Name
Test
Register
Units
Scale
Group
➀
Alarm
Type
➁
Standard Speed Alarms (1 Second)
01 Over Current Phase A Over Ia 1100 Amperes A 010
02 Over Current Phase B Over Ib 1101 Amperes A 010
03 Over Current Phase C Over Ic 1102 Amperes A 010
04 Over Current Neutral Over In 1103 Amperes B 010
05 Current Unbalance, Max I Unbal Max 1110 Tenths % — 010
06 Current Loss Current Loss 3262 Amperes A 053
07 Over Voltage Phase A–N Over Van 1124 Volts D 010
08 Over Voltage Phase B–N Over Vbn 1125 Volts D 010
09 Over Voltage Phase C–N Over Vcn 1126 Volts D 010
10 Over Voltage Phase A–B Over Vab 1120 Volts D 010
11 Over Voltage Phase B–C Over Vbc 1121 Volts D 010
12 Over Voltage Phase C–A Over Vca 1122 Volts D 010
13 Under Voltage Phase A Under Van 1124 Volts D 020
14 Under Voltage Phase B Under Vbn 1125 Volts D 020
15 Under Voltage Phase C Under Vcn 1126 Volts D 020
16 Under Voltage Phase A–B Under Vab 1120 Volts D 020
17 Under Voltage Phase B–C Under Vbc 1121 Volts D 020
18 Under Voltage Phase C–A Under Vca 1122 Volts D 020
19 Voltage Unbalance L–N, Max V Unbal L-N Max 1136 Tenths % — 010
20 Voltage Unbalance L–L, Max V Unbal L-L Max 1132 Tenths % — 010
21
Voltage Loss (loss of A,B,C, but
not all)
Voltage Loss 3262 Volts D 052
22 Phase Reversal Phase Rev 3228 — — 051
23 Over kW Demand Over kW Dmd 2151 kW F 011
24 Lagging true power factor Lag True PF 1163 Thousandths — 055
➀ Scale groups are described in Table 6–2 on page 80.
➁ Alarm types are described in Table 6–5 on page 83.
