Parameterization
9.4 Parameters
3KC ATC6500 transfer control device
178 Manual, 05/2019, L1V30538268002A-01
P10
Designation on
ATC display
Description
Unit
Default
Range
P10.n.12
REMOTE IP
PORT
Remote IP port (cannot be selected for COM1)
- See parameter 10.n.11
1001 0-32000
P10.n.13
GATEWAY IP
ADDRESS
IP gateway address (cannot be selected for COM1)
- See parameter 10.n.11
000.000.
000.000
000.000.000.000
–
255.255.255.255
9.4.11 P11 - Automatic Test
P11
Designation on
ATC display
Description
Unit
De-
fault
Range
P11.01
AUTO TEST
ENABLE 1
Enabling of the automatic test on Generator 1
- Enables the execution of the periodic test. This parameter can be
modified directly from the front operator panel, without invoking the
setup procedure. Its current status is displayed on the correspond-
ing display page, see chapter Automatic test (Page 67).
OFF OFF /
ON
P11.02
AUTO TEST
ENABLE 2
Enabling of the automatic test on Generator 2
- as for P11.01, but relating to Generator 2.
OFF OFF /
ON
P11.04
AUTOTEST
PERIOD
Interval for performing the TESTS
– Interval between two periodic tests. If the test is not enabled on
the day it becomes due, the period is extended to the next enabled
day.
gg 7 1-60
P11.05
AUTO TEST
MONDAY
TEST execution on Monday
- Enables the performance of the automatic test on the individual
days of the week.
OFF means that the test is not performed on that day of the week.
OFF OFF /
ON
P11.06
AUTO TEST
TUESDAY
TEST execution on Tuesday
- See parameter P11.05
OFF OFF /
ON
P11.07
AUTO TEST
WEDNESDAY
TEST execution on Wednesday
- See parameter P11.05
OFF OFF /
ON
P11.08
AUTO TEST
THURSDAY
TEST execution on Thursday
- See parameter P11.05
OFF OFF /
ON
P11.09
AUTO TEST
FRIDAY
TEST execution on Friday
- See parameter P11.05
OFF OFF /
ON
P11.10
AUTO TEST
SATURDAY
TEST execution on Saturday
- See parameter P11.05
OFF OFF /
ON
P11.11
AUTO TEST
SUNDAY
TEST execution on Sunday
- See parameter P11.05
OFF OFF /
ON
P11.12
START HOUR
Start hour of TEST
- Specifies the hours and the minutes for the start of the periodic
test
h 12 00-23
P11.13
START MINUTE
Start minute of TEST
- See parameter 09.11
min 0 00-59
