Acyclic data exchange via PROFIBUS DP
An acyclic data exchange takes place between the SIMATIC PDM and the PG/PC (ET 200iSP). The
ET 200iSP is con󹪝gured via acyclic data exchange. In addition, identi󹪝cation and maintenance
data is transmitted and displayed in SIMATIC PDM.
• Diagnostics and interrupts (with S7 DP device and DPV1 device)
• Data records
Software requirements
Table 7-1 Software requirements
Con󹪝guration software used Version Explanations
STEP 7 PROFINET: STEP 7 as of V5.7 SP1
and current hardware update
The ET 200iSP is included in the
hardware catalog of HW Con󹪝g.
You con󹪝gure and parameterize
the ET 200iSP with HW Con󹪝g.
PROFIBUS: STEP 7 as of V5.3 SP1
and current hardware update
STEP 7 and SIMATIC PDM (SIMAT‐
IC PDM is integrated and availa‐
ble as "stand-alone" version)
STEP 7 as of V4.02 You need the GSD 󹪝le from the
ET 200iSP and con󹪝gure with HW
con󹪝g...
PROFINET: SIMATIC PDM as of
V9.2.2
... and con󹪝gure them with SI‐
MATIC PDM.
PROFIBUS: SIMATIC PDM as of
V6.0
PCS 7 (contains, among other
things, STEP 7 and SIMATIC PDM)
PROFINET: PCS 7 as of V9.1 SP2 See documentation for PCS 7
PROFIBUS: PCS 7 as of V6.1
PCS neo PROFINET: PCS neo as of V4.0 See documentation for PCS neo
PROFIBUS: PCS neo as of V3.0
TIA Portal PROFINET: TIA Portal as of V18 See documentation for TIA Portal
PROFIBUS: TIA Portal as of V13
COM PROFIBUS and SIMATIC PDM
(SIMATIC PDM is integrated and
available as "stand-alone" ver‐
sion)
COM PROFIBUS as of V5.0 You need the GSD 󹪝le from the
ET 200iSP and con󹪝gure with
COM PROFIBUS...
PROFINET: SIMATIC PDM as of
V9.2.2
... and con󹪝gure them with SI‐
MATIC PDM.
PROFIBUS: SIMATIC PDM as of
V5.2
Other con󹪝guration software
and SIMATIC PDM (SIMATIC PDM
is integrated and available as
"stand alone" version)
Other con󹪝guration software
(see manufacturer for version)
You need the GSD 󹪝le from the
ET 200iSP and con󹪝gure with a
suitable con󹪝guration software...
PROFINET: SIMATIC PDM as of
V9.2.2
... and con󹪝gure them with SI‐
MATIC PDM.
PROFIBUS: SIMATIC PDM as of
V5.2
Commissioning and Diagnostics
7.1 Basics of commissioning and diagnostics
ET 200iSP
158 Operating Instructions, 11/2022, A5E00247483-AK
